Dimensions / Weights - SPX FLOW APV DELTA SD4 Series Instruction Manual

APV
APV_SD4_ATEX_UK-0_122018.indd
housing variants
SD 41
SD 42
Dimensions in mm
DN A
25 337
40 343
50 380
65 388
80 440
100 450
Inch
1" 335
1,5" 341
2" 379
2,5" 385
3" 436
4" 448
11
8. Dimensions / Weights
F
∅ Di
26 50
38 67
50 72
66 85
81 98
100 111
22,6 50
34,9 67
47,6 72
60,3 85
72,9 90
97,6 111
Ø K
G F
G ∅ K
126 86
129 86
133 126
145 126
153 189
162 189
126 86
129 86
133 126
142 126
148 189
162 189
UK
Weight
in kg
L
387 5
410 5
452 7
473 7
538 13
561 15
385 5
408 5
451 7
470 7
526 13
559 15
Double seal valve
DELTA SD4-ATEX
Instruction Manual: UK - rev. 0
