Constant Pressure Diaphragm Valve
DELTA CPV
Instruction Manual: UK – rev. 3
8.

Dimensions / Weights

CPV - o/c
Ø D
Ø 12x1
Ø C
A
ref.-No. A
20-16-444/.. 95
20-16-445/.. 95
20-16-446/.. 95
20-16-447/.. 95
20-16-469/.. 95
20-16-470/.. 95
20-16-471/.. 95
20-16-472/.. 95
B Ø C Ø D Ø E
190 50 160
190 50 160
230 50 160 130
230 50 160 130
190 47,6 160
190 47,6 160
230 47,6 160 130
230 47,6 160 130
CPV - o/c booster
Ø E
Ø D
Ø 12x1
Ø C
A
inst. dimension
F
X in mm
50 80
50 80
50 80
50 80
50 80
50 80
50 80
50 80
UK
weight
in kg
2,3
2,3
4,2
4,2
2,3
2,3
4,2
4,2
6
