Installation Instructions for Altronix Power Supplies and Sub-Assemblies to THW2:
1.
Fasten standoffs (provided) into pem configuration (A) or (B) of backplane (Fig. 2, pg. 2).
2.
Mount boards to standoffs utilizing 5/16" pan head screws (provided) (Fig. 2a, pg. 2).
3.
Mount backplane to enclosure with hardware.
Access Controller Position Chart for the Following Models:
Altronix Board
Altronix Power Supply/Charger or
Sub-Assembly
Altronix Sub-Assembly
Fig. 2
Metal Standoff Placement
Metal Standoff Placement
Metal Standoff Placement
Metal Standoff Placement
TroveHW
Pem Mounting
A
B
A
B
A
B
A
B
A
Fig. 2a
Pem
Standoff
Altronix
Pan Head
Power Supply or
Screw
Sub-Assembly
Backplane
- 3 -
