Access & Power Integration
Trove2BH2
- Trove2 enclosure with Altronix/Bosch backplane (TBH2)
TBH2
- Altronix/Bosch backplane only
TBHD2
- Bosch door backplane only
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TBH110419
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
SIGNALING
More than just power.™
Advertisement
Related Manuals for Altronix Trove2BH2
Summary of Contents for Altronix Trove2BH2
- Page 1 SIGNALING Access & Power Integration Trove2BH2 - Trove2 enclosure with Altronix/Bosch backplane (TBH2) TBH2 - Altronix/Bosch backplane only TBHD2 - Bosch door backplane only Installation Guide More than just power.™ All registered trademarks are property of their respective owners. Rev. TBH110419 Installing Company: _________________________ Service Rep.
-
Page 2: Agency Listings
Overview: Trove2BH2 accommodates various combinations of Bosch boards with or without Altronix accessories for access control systems. Agency Listings: • UL 294 - 6th edition: Line Security I, Destructive Attack I, Endurance IV, Stand-by Power II*. * Stand-by Power Level I if no battery is supplied. - Page 3 Installation Instructions for Altronix Sub-Assemblies to TBH2: 1. Insert screw (provided) into hole configuration (A) from the backside of backplane (Fig. 2a, pg. 3). Screw spacer onto screws, repeat for additional three (3) board mounting holes. 2. Mount boards to spacers utilizing 5/16” pan head screws (provided) (Fig. 2a, pg. 3).
- Page 4 D125B, D129, D132A, D185, D192G, D8130 SDI/2 Devices* B208, B308, B426, B450, ICP-SDI-9114 Fig. 3 * These boards have the same keyhole mounting bracket (Fig. 3, pg. 4). Position them according to your specific design. - 4 - Trove2BH2 Installation Guide...
- Page 5 Bosch Board(s) Mounting Access Control* B901 Expansion Modules* B299, B600, D8128D, D8125/MUX, D8129 Interface Cards* D125B, D129, D132A, D185, D192G, D8130 SDI/2 Devices* B208, B308, B426, B450, ICP-SDI-9114 Controllers D7412GV4, D9412GV4, B8512G, B9512G Fig. 4 Trove2BH2 Installation Guide - 5 -...
- Page 6 TBH2 Dimensions 25.375” x 19.375” x 0.3125” (644.5mm x 482.6mm x 7.9mm). 19.375” (492.1mm) 2.2” (55.9mm) 2.2” (55.9mm) 0.156” ( 3.96mm) 1.0” (25.4mm) 1.0” (25.4mm) 7.5” (190.5mm) 7.5” (190.5mm) 9.2” (233.7mm) 9.2” (233.7mm) - 6 - Trove2BH2 Installation Guide...
- Page 7 TBHD2 Dimensions 23.75” x 18.125” x 0.3125” (603.3mm x 460.3mm x 7.9mm). 18.125” (460.3mm) 13.7” (350mm) 0.156” ( 4mm) 0.45” (11.4mm) 8.7” 8.7” (221mm) (221mm) 11.8” (299.7mm) 13.7” (350mm) Trove2BH2 Installation Guide - 7 -...
- Page 8 5.25” (133.4mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. IITrove2BH2 I24U MEMBER...
