- Page 1 Access & Power Integration Trove2M2R Trove rack enclosure with Altronix and Mercury Backplane (TM2R) Installation Guide All registered trademarks are property of their respective owners. SIGNALING More than just power. Rev. 122222 Installing Company: _______________ Service Rep. Name: __________________________________ Address: _____________________________________________ Phone #: __________________...
- Page 2 Overview: Altronix Trove2M2R rack mount access & power integration solution consists of a high-capacity rack enclosure with removable backplane. This unit easily accommodates various combinations of Mercury boards with or without Altronix power supplies and accessories in a streamlined package for access systems.
- Page 3 6. Secure the rack cover (Fig. 2a, pg. 3) and rack drawer (Fig. 2b, pg. 3) to earth ground. 7. Ensure that all internal cofigurations (voltage selection, switch settings, etc.) are completed before mounting backplane back into Trove rack enclosure. Fig. 2 Fig. 2a Fig. 2b Trove2M2R Installation Guide - 3 -...
- Page 4 Z Bracket Installation for Trove2R: Altronix Trove2R enclosure includes Z Bracket, a convenient and reliable wire management accessory. Hardware (included): Fig. 3 Twelve (12) bolts and eight (8) lock nuts. 1. Carefully unpack Z Bracket. Do not discard hardware (included) (Fig. 3, pg. 4).
- Page 5 TM2R: Configuration of Altronix Power Supply and/or Sub-Assembly Boards and Mercury Boards 1. Fasten spacers onto metal pems configuration of backplane depending on the board (Fig. 6, pg. 5). 2. Position module over corresponding spacers and fasten screws into spacers (Fig. 6a, 6b, pg. 5).
- Page 6 Notes: - 6 - Trove2M2R Installation Guide...
- Page 7 TM2R Backplane Dimensions (H x W x D): 3.375” x 19.0” x 33.25” (85.8mm x 482.6mm x 844.6mm) 14.3” (363.2mm) Trove2M2R Installation Guide - 7 -...
- Page 8 0.63” (16mm) 0.52” (13.2mm) 4.5” (114.3mm) 11.2” (284.5mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IITrove2M2R...
