Access & Power Integration
Trove1V1
- Trove1 enclosure with Altronix/HID VertX
TV1
- Altronix/HID VertX
Trove2V2
- Trove2 enclosure with Altronix/HID VertX
TV2
- Altronix/HID VertX
TMV2
- Altronix/HID VertX
Trove3V3
- Trove3 enclosure with Altronix/HID VertX
TV3
- Altronix/HID VertX
Installation Guide
All registered trademarks are property of their respective owners.
Rev. THID011117
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
backplane only
®
backplane only
®
Door Backplane. Fits Trove2 and Trove3 enclosures
®
backplane only
®
backplane (TV1)
®
backplane (TV2)
®
backplane (TV3)
®
SIGNALING
More than just power.™
Advertisement
Related Manuals for Altronix Trove1V1
Summary of Contents for Altronix Trove1V1
- Page 1 SIGNALING Access & Power Integration Trove1V1 - Trove1 enclosure with Altronix/HID VertX backplane (TV1) ® - Altronix/HID VertX backplane only ® Trove2V2 - Trove2 enclosure with Altronix/HID VertX backplane (TV2) ® - Altronix/HID VertX backplane only ® TMV2 - Altronix/HID VertX Door Backplane.
-
Page 2: Agency Listings
Overview: Altronix Trove1V1, Trove2V2 and Trove3V3 accommodate various combinations of HID VertX boards with or without Altronix power supplies ® and sub-assemblies for access systems. Agency Listings: • UL 294 - 6th edition: Line Security I, Destructive Attack I, Endurance IV, Stand-by Power II (Stand-by Power Level I if no battery is supplied). - Page 3 Install the two/three lower screws and make sure to tighten all screws. Tamper Switch 3. Mount included UL Listed tamper switch(es) (Altronix Model TS112 or equivalent) in desired (included) location, opposite hinge. Slide the tamper switch bracket onto the edge of the enclosure approximately 2”...
- Page 4 Altronix Power Supplies/Chargers and/or Sub-Assemblies: 1. Fasten spacers (provided) to pems that match the hole pattern for Altronix Power Supply/Chargers or Altronix Sub-Assembly boards (positions (A) and (B), Fig. 2, pg. 4). Use snap on nylon spacers for the upper two mounting holes in the board.
- Page 5 TV2 Sub-Assembly Position Chart for the Following Models: Altronix Power Supplies/Sub-Assemblies Sub-Assembly Pem Mounting Input Rating Output Rating AL400ULXB2 115VAC, 60Hz, 3.5A 12VDC @ 4A or 24VDC @ 3A AL600ULXB 115VAC, 60Hz, 3.5A 12VDC or 24VDC @ 6A AL1012ULXB 115VAC, 60Hz, 2.6A...
- Page 6 Installation Instructions for Altronix Sub-Assemblies to TV2: 1. Fasten spacers (provided) to pems that match the hole pattern for Altronix Power Supply/Chargers, Sub-Assembly boards or adapters. Use snap on nylon spacers for the upper two mounting holes in the board.
- Page 7 Installation Instructions for HID VertX Sub-Assemblies to TV2: ® 1. Fasten spacers (provided) onto metal pems configuration (A) of backplane (Fig. 4, pg. 7). 2. Mount boards to spacers utilizing 7/8” pan head screws (provided) (Fig. 4a, pg. 7). 3. Fasten backplane to Trove2 enclosure utilizing lock nuts (provided). TV2 Sub-Assembly Position Chart for the Following Models: HID VertX Sub-Assemblies...
- Page 8 Altronix Sub-Assemblies and/or Adapters: 1. Fasten nylon / snap on spacers to pems which match the hole pattern for Altronix Sub-Assemblies (Fig. 5, 5b, pg. 8). 2. Mount boards to spacers utilizing pan head screws provided with the product or by depressing board onto snap on spacer (Fig. 5, pg. 8).
- Page 9 TV3 Sub-Assembly Position Chart for the Following Models: Altronix Power Supplies/Sub-Assemblies Sub-Assembly Pem Mounting Input Rating Output Rating AL400ULXB2 115VAC, 60Hz, 3.5A 12VDC @ 4A or 24VDC @ 3A AL600ULXB 115VAC, 60Hz, 3.5A 12VDC or 24VDC @ 6A AL1012ULXB 115VAC, 60Hz, 2.6A...
- Page 10 Installation Instructions for Altronix Sub-Assemblies to TV3: 1. Fasten spacers (provided) to pems that match the hole pattern for Altronix Power Supply/Chargers, Sub-Assembly boards or adapters. Use snap on nylon spacers for the upper two mounting holes in the board.
- Page 11 Installation Instructions for HID VertX Sub-Assemblies to TV3: ® 1. Fasten spacers (provided) onto metal pems configuration (A) of backplane (Fig. 7, pg. 11). 2. Mount boards to spacers utilizing 7/8” pan head screws (provided) (Fig. 7a, pg. 11). 3. Fasten backplane to Trove2 enclosure utilizing lock nuts (provided). TV3 Sub-Assembly Position Chart for the Following Models: HID VertX Sub-Assemblies...
- Page 12 - UL Listed in the U.S. and Canada. - Local or remote control of up to (2) two Altronix eFlow power output(s) via LAN and/or WAN. - Monitor real time diagnostics: DC output voltage, output current, AC & battery status/service, input trigger state change, output state change and unit temperature.
- Page 13 Notes: Trove / HID VertX Installation Guide - 13 -...
- Page 14 Trove1 Enclosure Dimensions (H x W x D approximate): 18” x 14.5” x 4.625” (457mm x 368mm x 118mm) 14.5” (321.3mm) 7.25” (184.2mm) 1.45” (36.8mm) 1.95” (49.5mm) 4.5” (114.3mm) 13.0” (330.2mm) 1.25” (31.8mm) 1.25” (31.8mm) 1.5” (38.1mm) 1.5” (38.1mm) 0.6” (15.2mm) 0.57”...
- Page 15 Trove2 Enclosure Dimensions (H x W x D approximate): 27.25” x 21.75” x 6.5” (692.15mm x 546.1mm x 165.1mm) 21.50” (546.1mm) 2.00” (50.8mm) 2.00” (50.8mm) 5.25” (133.35mm) 3.5”(88.9mm) 3.5”(88.9mm) 5.25” (133.35mm) 0.685” (17.4mm) 1.25” Knockouts 0.5625” (14.3mm) (31.8mm) 1.77” 1.125” (28.3mm) (45mm) 2.415”...
- Page 16 8.75” (222.3mm) 8.62” (219mm) 8.75” (222.3mm) 2” (50.8mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com IITrove / HID VertX...
