8 Chapter 1: Introduction
Matrox Radient eCL boards
Matrox Radient eCL is a family of high-performance PCIe frame grabbers that
acquire images from Camera Link video sources and offer FPGA-based processing
offload capabilities.
There are four Matrox Radient eCL members: eCL-DB, eCL-QB, eCL-SF, and
eCL-DF. Matrox Radient eCL-DB and eCL-QB support acquisition from Camera
Link video sources in Base configuration; eCL-DB supports simultaneous
acquisition from two of these video sources, whereas eCL-QB supports four
simultaneously. Matrox Radient eCL-SF and eCL-DF support acquiescing from
Camera Link video sources in Medium or Full configuration (with up to 10 taps);
eCL-SF supports acquisition from one of these video sources, whereas eCL-DF
supports two simultaneously.
Matrox Radient eCL supports power-over Camera Link (PoCL) compliant video
sources and Camera Link frequencies of 20 MHz to 85 MHz.
This manual uses the term Matrox Radient eCL to refer to all members of Matrox
Radient eCL. It uses the term Matrox Radient eCL-DB/QB to refer to both
Matrox Radient eCL-DB and eCL-QB. It uses the term Matrox Radient
eCL-SF/DF to refer to both Matrox Radient eCL-SF and eCL-DF. When
necessary, this manual distinguishes between the boards using their full names.
