72 Appendix B: Technical information
Dimensions and environmental
specifications
The following dimensions and environmental specifications apply to both Matrox
Radient eCL-DB/QB and eCL-SF/DF:
• Dimensions of Matrox Radient eCL-DB and eCL-SF:
16.76 L x 11.12 H x 1.871 W cm (6.6" x 4.376" x 0.737") from bottom edge of
goldfinger to top edge of board.
• Dimensions of Matrox Radient eCL-QB and eCL-DF:
16.76 L x 11.12 H x 3.903 W cm (6.6" x 4.376" x 1.537") from bottom edge of
goldfinger to top edge of board.
• Ventilation: 200 LFM between boards.
• Minimum/maximum ambient operating temperature: 0°C to55°C
(32°F to 131°F).
• Minimum/maximum storage temperature: -40°C to 75°C (-40°F to 167°F).
• Operating relative humidity: up to 95% relative humidity (non-condensing).
• Storage humidity: up to 95% relative humidity (non-condensing).
*. Up to RAD2G|DF|QB|200432* configuration. Maximum temperature might
decrease for larger Processing FPGAs.
*
