8.2.15 Working with Mirror modes

Using the Mirror mode:
chosen layer and go in the layer menu, then select the "Layer Copy Mode" menu. There are several mirror
positioning options:
1. No Copy: this mode is the standard Matrix mode, output #1 and #2 are independent.
2. Clone mode: Outputs #1 and #2 will be the same. All changes on output #1 will be affected to output #2.
Layers will have the same position and size.
OUTPUT #1
3. Copy & H.pos Flip mode:
OUTPUT #1
NOTES:
• Remember to simplify the use of this feature, you need to manipulate Output #1. While in mirror mode,
Output #2 will follow.
• Every change on Output #2 will have an effect only on Output #2, but remember that if a change occurs on
Output #1 after that, Output #2 will update automatically to match output 1.
58
the mirror mode can be activated layer by layer thanks to the layers menu. Select the
OUTPUT #1
OUTPUT #2
Output #2 will be exactly the same as output #1 except the fact that the selected
layer will have its H position flipped (standard Mirror mode).
OUTPUT #2
OUTPUT #2
OUTPUT #1 OUTPUT #2
OUTPUT #1 OUTPUT #2
