4.6 Input specifications
Each input can display only one active plug at a time. It is instantly available on the device and can be dis-
played simultaneously on many layers or outputs, with different sizes and positions.
Standard Size
NTSC 525/480i
PAL 625/576i
SECAM 625/576i
EDTV 480p 525/480p
EDTV 576p 625/576p
HDTV 720p 1280x720
HDTV 1035i 1920x1035
HDTV 1080i 1920x1080
HDTV 1080p 1920x1080
HDTV 1080sF 1920x1080
HDTV 1080p 1920x1080
HDTV DCDM 2048x1080
VGA 640x480
800x480 800x480
WVGA 848x480
SVGA 800x600
1280x600 1280x600
720p RGB 1280x720
XGA 1024x768
WXGA 1280x768
SWXGA 1360x768
1366x768 1366x768
800p RGB 1280x800
SWXGA+ 1366x800
1152x864 1152x864
900p RGB 1440x900
1600x900 1600x900
960p RGB 1280x960
SXGA 1280x1024
1360x1024 1360x1024
DILA4/3 1364x1024
SXGA+ 1400x1050
WSXGA+ 1680x1050
1080p RGB 1920x1080
2K 2048x1080
Q WXGA 2048x1152
UXGA 1600x1200
WUXGA 1920x1200
Note:
1) Reduced Blanking
18
HD-15 3G-SDI HDMI
Yes Yes
Yes Yes
Yes Yes
Yes No
Yes No
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
Yes Yes
No Yes
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
Yes No
1
Yes No
1
Yes No
1
Yes No
1
Yes No
1
Single-Link
HDBaseT
DVI-D
Yes Yes No
Yes Yes No
Yes Yes No
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
No No No
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
Yes Yes Yes
1 1
Yes Yes Yes
1 1
Yes Yes Yes
1 1
Yes Yes Yes
1 1
Yes Yes Yes
1 1
1
1
1
1
1
