7.3.3 Effects
Layer position
A layer position shortcut is also available. After having selected a layer, simply click on
the Pos. button to have quickly access to a layer position. Choose the new position. The
change is applied straight away on your preset.
Layer size
You can choose between several aspect ratio. Once selected, the new aspect ratio is
applied on the selected layer.
Other layer adjustments:
- CLEAR BUTTON:
- CLEAR ALL BUTTON:
- CONTENT SIZE:
- SCREEN SIZE:
- LAYER SIZE/SOURCE RATIO:
- ALIGN BUTTON:
vertically (use Shift to select 2 layers),
- KEEP ASPECT RATIO BUTTON:
- WIREFRAME MODE:
- SHOW LAYER OUT OF SCREEN:
into the RCS²,
- TRAP LAYERS ON SCREEN:
- HIDE UNUSED LAYERS:
- TOGGLE PRESET:
- RELOAD PROGRAM:
- STEP BACK:
return to the configuration you had before the last TAKE,
- MIRROR BUTTON:
way it will be copied in the preset. You can choose to mirror the layer or flip
the position.
46
this button allows you to clear the selected layer from your preset,
remove all layers from your preset,
set layer size to its content size,
set layer size to screen size,
set the layer size to fit the source ratio,
you need first to select at less 2 layers, then you can align them horizontally or
enabling this feature will keep the layer aspect ratio during resizing,
allows to enable/disable the layer thumbnails on your RCS²,
enable/disable the possibility to display a layer out of the screen
disable the ability to position the layer off of the screen,
empty layers will not be displayed in the RCS²,
enable/disable the TOGGLE PRESET (the Preview becomes the previous Program),
load the preset of the Program screen into the Preview screen,
the mirror button allows you to define for each layer the
