7.3.1 Layer management
Erase memories
Into this section, you can erase individual settings.
• Erase input settings memory: all input settings will return to their default value. This includes image, aspect,
user format and keying parameters.
• Erase thumbnail: all the thumbnails you store on your computer will be erased.
• Erase device preset memories
• Erase local preset memories
• Erase custom formats
Factory reset
Click on start to erase all settings (except network and RCS² parameters). The unit will reboot itself after the
factory reset.
7.3 Edit
7.3.1 Layer management
When you enter into the Edit menu, you
will encounter by default this window.
On this example, we have the Screen 1
Program and the Screen 1 Preview. The
following example can be applied for any
other screen configurations.
To display an input into the available
layer A, simply drag and drop the input
from the left column to the layer on the
chosen screen. You can assign or change
the inputs directly on Program as well as
Preview.
