DSC 3G2060 Installation Manual

Internet/hspa alarm communicator
Hide thumbs
Table of Contents

Advertisement

Quick Links

3G2060
HSPA Cellular Alarm Communicator – International
TL2603G
Internet and HSPA Dual-path Alarm Communicator –
International
TL260
Internet Alarm Communicator – International
I
M
3.0
NSTALLATION
ANUAL V
Warning: This manual contains information on limitations regarding product use and func-
tion and information on the limitations as to liability of the manufacturer.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 3G2060 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for DSC 3G2060

Summary of Contents for DSC 3G2060

  • Page 1 3G2060 HSPA Cellular Alarm Communicator – International TL2603G Internet and HSPA Dual-path Alarm Communicator – International TL260 Internet Alarm Communicator – International NSTALLATION ANUAL V Warning: This manual contains information on limitations regarding product use and func- tion and information on the limitations as to liability of the manufacturer.

  • Page 3: Table Of Contents

    ABLE OF ONTENTS General ............1 Communicator Frequency Bands by Market .
  • Page 4 WARNING: I NSTALLER LEASE AREFULLY Note to Installers Motion Detectors The Warnings on this page contain vital information. As the only Motion detectors can only detect motion within the designated areas individual in contact with system users, it is the installer’s responsi- as shown in their respective installation instructions.

  • Page 5: General

    Communicator Placement Test below to determine the best location for radio reception (minimum of one green LED ON). NOTE: Prior to installation of the 3G2060 or TL2603G Communicator, confirm with your local service provider that the HSPA(3G)/GPRS network is available and active in the area where the communicator will be installed, and that radio signal strength (CSQ) is adequate.

  • Page 6: Communicator Frequency Bands By Market

    General 3G Alarm Communicator Installation Manual Features • 128-bit AES encryption via cellular and Internet (NIST Validation Certificate No. 2032). • Back up or primary cellular alarm communication. • Automatically switches to 2G (EDGE/GPRS) if HSPA(3G) service is not available. •...

  • Page 7: Ratings Compatibility

    DLS 5connections. You must send an SMS message to the unit, therefore, you must know the phone number assigned to the SIM. 1. Run the DLS 5 software on your computer. If required, download the DLS 5 software from DSC: http://www.dsc.com/index.php?n=library#self.

  • Page 8: Communicator Installation Configuration

    NOTE: You can disable DLS over cellular. Refer to Programming Worksheets Section [006] Tog- gle Option [7]. If you disable DLS over cellular, remote programming will not work on the 3G2060 Communicator, regardless of the path set in Programming Options Section [005] Toggle Option [4].

  • Page 9: Installing Cellular/Ethernet Communicator In Panel

    Installing Cellular/Ethernet Communicator in 3G Alarm Communicator Installation Manual 6. Insert or remove the SIM card, noting the orientation of the notches on the SIM card and the SIM card holder. 7. When inserting a SIM card, insert the card in the proper orientation and gently push the SIM card holder down and slide the holder as indicated by the arrow on SIM holder, to LOCK.
  • Page 10 RJ-45 threaded antenna connection point at top of the panel. WARNING! - 3G2060/TL2603G/TL260 modules are power limited. Do not route any wiring over the circuit board. Maintain at least 1in. (25.4mm) sepa- ration between circuit board and wiring. A mini- mum of ¼...
  • Page 11 Input Ratings from Bell +: to reset. +11.1V ~ +12.6 VDC 100mA standby; 400mA alarm TL2603G(R) Network Link UA601 TL260(R) YELLOW DSC Panel min. power requirements: 3G2060(R) - 16 VAC 40 VA transformer; - 12 VDC 7Ah battery RJ-45 PC-LINK PC1616/1832/1864 From NID Black...

  • Page 12: Communicator Placement Test

    3G Alarm Communicator Installation Manual OMMUNICATOR LACEMENT 3G2060 and TL2603G only To confirm that the cellular antenna location is suitable for radio operation, perform the placement test as follows: NOTE: You may need to relocate the Panel or install an optional extension antenna during this procedure, if radio signal strength is too low.
  • Page 13 3. A valid Account Number must be entered in Communicator Section [851][021]. See Program- ming Section. NOTE: DSC recommends using the same Account Number for Panel and Communicator. 4. In Panel Sections [301], [302], and [303], program the central station telephone number that will be used for the cellular/Ethernet Communicator.

  • Page 14: Communicator Status Leds

    Communicator Status Leds 3G Alarm Communicator Installation Manual • T-LINK Network Fault/Restore: This log will occur for the following trouble conditions: SIM Lock Trouble, cellular Trouble, Ethernet Trouble, or Connect24 Configuration Trouble. • T-LINK Receiver Trouble/Restore: This log will occur for the following trouble conditions: Receiver Not Available Trouble, Receiver Supervision Trouble, or Failure to Communicate (FTC) Trouble.
  • Page 15 Communicator Status Leds 3G Alarm Communicator Installation Manual SIM Lock Trouble (4 Flashes) (3G2060(R)/Tl2603G(R) only) This trouble will signify that the SIM lock feature has been enabled and the unit has not been pro- grammed with the correct PIN for the SIM card.

  • Page 16: Communicator Reset / Update

    Communicator Reset / Update 3G Alarm Communicator Installation Manual NOTE: If the yellow LED is flashing, Signal Strength in table below is not valid. See Table 7 for troubleshooting flashing yellow LED. Table 8: Radio Signal Strength Signal Yellow Green Green Signal Action Required...
  • Page 17 Communicator Troubleshooting 3G Alarm Communicator Installation Manual OMMUNICATOR ROUBLESHOOTING NOTE: For additional details: • Refer to Section [983] for troubleshooting the firmware updates • Refer to Section [984] to verify the trouble status • Refer to Section [985] for troubleshooting Connect24 programming Table 9: Trouble LED indications Trouble Possible...

  • Page 18: Ethernet/Cellular Programming Options

    Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual THERNET ELLULAR ROGRAMMING PTIONS The Programming Sections described in this document can be viewed at the keypad LCD. To start programming enter: [*][8][installer code] [851][# # # ], Where # # # is the 3 digit section number referenced in this section.
  • Page 19 [4] Primary Path Default (OFF - TL2603G/TL260) (ON - 3G2060) ON: Cellular channel is the primary path. Ethernet channel is the secondary path, if it exists. OFF: Ethernet channel is the primary path in a dual Communicator. Cellular channel is the second- ary path.

  • Page 20: Programming Options

    Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual [2] Ethernet 2 Receiver Enabled. Default (ON) (OFF for 3G2060). ON: Ethernet Receiver 2 is enabled. OFF: Ethernet Receiver 2 is disabled. [3] Reserved. ( ). [4] Cellular 1 Receiver Enabled. Default (OFF for TL2603G/TL260) (ON).

  • Page 21: Communications Reporting Codes

    Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual [013] DLS Outgoing Port Default (0BFA/3066) The DLS Outgoing Port is used for outgoing session to DLS IV after an SMS request has been sent to the Communicator. Use this Section to set the value of the local outgoing port. The value must be changed if the Communicator is located behind a firewall and must be assigned a particu- lar port number, as determined by your network administrator.
  • Page 22 Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual [025] Radio Activation Restore Default (FF) Program 00 to disable this event or FF to enable. This event will occur after any successful Con- nect24 programming session. System Test Options [026 - 029] Test Transmissions to Primary Receiver, with Backup to Secondary Receiver: Set Ethernet Section [026] to (FF);...
  • Page 23 Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual [029] Cellular 2 Transmission Default (00) Program 00 to disable this event transmission or FF to enable. See System Test Options (above) for details on settings. NOTE: The time interval (in minutes) between periodic tests is programmed in Section [125] (Ethernet) and Section [225] (Cellular).

  • Page 24: Ethernet Receiver 1 Options

    Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual [037] Panel Firmware Update Fail Default (FF); Program 00 to disable this event transmission or FF to enable. This event will occur when the panel firmware updated has failed. Table 11: Panel Tamper Alarm Restore Contact Contact Contact...

  • Page 25: Ethernet Receiver 2 Options

    Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual [105] Ethernet Receiver 1 Local Port Default (0BF4/3060) Use this Section to set the value of the local outgoing port. Set the value of this port when your installation is located behind a firewall and must be assigned a particular port number as deter- mined by your central station system administrator.

  • Page 26: Ethernet Options

    Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual NOTE: Do not program Ethernet Receiver 1 and Ethernet Receiver 2 Port with the same value. [116] Ethernet Receiver 2 Domain Name Default ( ) Enter the Domain Name as 32 Character ASCII. Ethernet Options [124] Ethernet Test Transmission Time Default (9999)

  • Page 27: Cellular Receiver 2 Options

    Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual [205] Cellular Receiver 1 APN Default ( ) The Access Point Name (APN) determines the Cellular network that the Communicator will con- nect to. This information is available from your network carrier. Program this Section as 32 ASCII characters.

  • Page 28: Cellular Options

    Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual Cellular Options [221] Cellular Public Access Point Name Default ( ) When the Communicator is operating on a private APN, use this Section to select a public APN for DLS and Remote Firmware Update. This information is available from your network carrier. The APN identifies the public Cellular network that the Communicator will connect to.

  • Page 29: System Information (Read Only)

    Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual System Information (Read Only) NOTE: Sections [987] - [998] are provided for information (Read Only). Values in these sections cannot be modified by the Installer. [987] Language Version This section will display the current Language version of the Communicator. [988] DNS 1 IP Address This section will display the IP address of DNS Server 1.

  • Page 30: System Reset Defaults

    Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual System Reset Defaults [999] Software Default Default (99); The Software default allows the installer to refresh the unit after changes and also return the Com- municator to the default state. 00: Default Module. All programming Sections in module revert to factory settings. This will erase all existing programming of the unit.
  • Page 31 Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual Reason Code Description of Reason Code Firmware Image is Communicator Firmware Update Complete Panel Firmware Update Complete File Download in Progress Firmware File Empty Software Default Value (Factory Default) File Receive Failure File Was Not Received Communicator Update Fail Firmware Update did Not Occur...
  • Page 32 Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual Table 16: Network Indicator - Digit 3 Network indicator Value Means No Network Trouble Ethernet Cable disconnected Ethernet DHCP failed Radio connection has been rest Radio IP failed Incoming transmission Flashing Outgoing transmission Incoming transmission Table 17: Trouble Code Indications - Digits 4 &...
  • Page 33 Ethernet/Cellular Programming Options 3G Alarm Communicator Installation Manual 2. Not Used 3. Radio reset 4. Radio attached to network 5. Receiver 1 Initialized 6. Receiver 2 Initialized 7. Receiver 3 Initialized 8. Receiver 4 Initialized For example, the radio initialization status code 12-45--- indicates that Radio has been powered up, the radio is attached to the network, and Receiver 1 has been initialized.

  • Page 34: Ethernet/Cellular Programming Worksheets

    |____| [2] Cellular Receiver 1 Supervised Default (OFF). |____| [3] Supervision Type Default (OFF). |____|____| |____| [4] Primary Communications Path. Default (ON - 3G2060). |____| [5] Redundant Communications Default (OFF). System Test Options [026 - 029] |____| [6] Remote Firmware Upgrade Default (ON).

  • Page 35: Ethernet Receiver 1 Options

    Ethernet/Cellular Programming Worksheets 3G Alarm Communicator Installation Manual [034] Communicator Firmware Update Suc- [113] Ethernet Receiver 2 Address cessful Default (000.000.000.000) Default (FF). Program 00 disable or FF enable. |____|____|____||____|____|____||____|____|____|____|____|____| |____|____| [114] Ethernet Receiver 2 Remote Port Default (0BF5/3061). Valid range: 0000 - FFFF. [035] Panel Firmware Update Begin |____|____|____|____| Default (FF).

  • Page 36: Cellular Receiver 2 Options

    Ethernet/Cellular Programming Worksheets 3G Alarm Communicator Installation Manual [206] Cellular Receiver 1 Domain Name [225] Cellular Test Transmission Cycle Default ( ) Default (000000) 32 Character ASCII characters. Valid range: 000000 - 999999 minutes. ____________________________________ |____|____|____|____|____|____| [226] Cellular Trouble Delay Cellular Receiver 2 Options Default (10) [211] Cellular Receiver 2 Account Code...

  • Page 37: Area Label Programming

    Ethernet/Cellular Programming Worksheets 3G Alarm Communicator Installation Manual Up to 32 digit telephone number . Blank is disabled. |____| [3] SMS Notification Opening/Closing Default (ON). ________________________________ |____| [4] SMS Notification System Maintenance Default (ON). |____| [5] SMS Notification System Test Default (ON). [321] SMS Telephone Number 1 Toggle Options |____| [6] SMS Notification Internal Events Default (ON).

  • Page 38: User Label Programming

    Ethernet/Cellular Programming Worksheets 3G Alarm Communicator Installation Manual [355] Partition 3 Label Default [Partition 3]. [378] User 18 Label Default [User 18]. ________________________________ ________________________________ [356] Partition 4 Label Default [Partition 4]. [379] User 19 Label Default [User 19]. ________________________________ ________________________________ [357] Partition 5 Label Default [Partition 5].
  • Page 39 Ethernet/Cellular Programming Worksheets 3G Alarm Communicator Installation Manual ________________________________ ________________________________ [402] Zone 2 Label Default [Zone 2]. [427] Zone 27 Label Default [Zone 27]. ________________________________ ________________________________ [403] Zone 3 Label Default [Zone 3]. [428] Zone 28 Label Default [Zone 28]. ________________________________ ________________________________ [404] Zone 4 Label Default [Zone 4].

  • Page 40: External Event Label Programming

    Ethernet/Cellular Programming Worksheets 3G Alarm Communicator Installation Manual ________________________________ [510] Gas Alarm Restore Default [Gas / Carbon Monoxide Restore]. [452] Zone 52 Label Default [Zone 52]. ________________________________ ________________________________ [511] Heat Alarm Default [High Temperature Alarm]. [453] Zone 53 Label Default [Zone 53]. ________________________________ ________________________________ [512] Heat Alarm Restore Default [High Temperature...
  • Page 41 Ethernet/Cellular Programming Worksheets 3G Alarm Communicator Installation Manual [534] Module Supervisory Restore [557] General System Trouble Default [General System Trouble]. Default [Module Supervisory Restore]. ________________________________ ________________________________ [558] General System Trouble Restore [535] General System Tamper Default [General System Tamper]. Default [General System Trouble Restore]. ________________________________ ________________________________ [536] General System Tamper Restore...

  • Page 42: Internal Event Label Programming

    Ethernet/Cellular Programming Worksheets 3G Alarm Communicator Installation Manual ________________________________ [615] Status Request Default [Status Request];. ________________________________ Internal Event Label Programming [616] Alarm Memory Request Default [Alarm Memory [591] Panel Absent Trouble Default [Panel Communica- Request]; tions ________________________________ Trouble]. ________________________________ [617] Help Default [Help]; [592] Panel Absent Trouble Restore ________________________________ Default [Panel Communications Restored].

  • Page 43: System Reset Defaults

    Ethernet/Cellular Programming Worksheets 3G Alarm Communicator Installation Manual [994] Cellular IP Address |____|____|____||____|____|____||____|____|____|____|____|____| [995] SIM Number ____________________________________ [996] Cellular Telephone Number This number is required for DLS, and Firmware upgrades. ____________________________________ [997] IMEI Number ____________________________________ [998] MAC Address |____| _ ___| _ ___| _ ___| _ ___| _ ___| | _ ___| _ ___| _ ___| _ ___| _ ___| _ ___| System Reset Defaults [999] Software Default |____|____|...
  • Page 44 If You do erned by the laws of the Province of Ontario, Canada. not agree to the terms of this EULA, DSC is unwilling to license the ARBITRATION - All disputes arising in connection with this SOFTWARE PRODUCT to You, and You have no right to use it.

  • Page 45: Limited Warranty

    ARRANTY Digital Security Controls (DSC) warrants the original pur- will be credited or replaced at DSC's option. Products not chaser that for a period of twelve (12) months from the date covered by this warranty, or otherwise out of warranty due to...
  • Page 48 EN50131 Compliant Installations 1. The TL2603G-EU, 3G2060-EU, TL260 module is monitored by the control panel and it is programmed via the programming menu (* 8, section [851] in the control panel. The interface is connected to the PC-Link bus as shown in the diagram included in this manual.
