2 – Core Parameters
Table 2-1 lists the Normal mode Hard Multiplier Accumulator settings;
mode settings.
Table 2-1 • Hard Multiplier Accumulator Normal Mode Configuration Description
Name Valid Range
Multiplier Functions
Function Multiplier
Accumulator
(Adder)
Multiplier
Accumulator
(Subtractor)
Multiplier
Accumulator
(Adder/Subtractor)
Input Port A0
Use Constant
Constant Value (Hex) -2
Width 2 to 18
Register Port
Input Port B0
Width 2 to 18
Register Port
Input Port C
Use Constant
Constant Value (Hex) -2
Width 2 to 44
Carry In
Description
The Multiplier Accumulator with Adder/Subtractor exposes the SUB
control signal, which enables you to dynamically toggle between an
add or subtract operation.
Sets input port A0 to constant
17 17
to (2 - 1) Two's complement value of A0, if A0 is constant. Values shorter than
18 bits are padded with zeros. Negative values must be a full 18 bits
wide. For example, 0x1FFFF means +131071 (2
means -1
Width of input port A0; if shorter than 18 bits it is sign-extended. For
example, if the width is 8, a value of 0x7F means +127 and a value of
0xFF means -1
Registers input port A0 (if A0 is not set to constant)
Width of input port B0; if shorter than 18 bits it is sign-extended. For
example, if the width is 8, a value of 0x7F means +127 and a value of
0xFF means -1.
Registers input port B0
Sets input port C to constant
43 43
to (2 - 1) Two's complement value of C, if C is constant. Values shorter than 44
bits are padded with zeros. Negative values must be a full 44 bits wide.
Width of input port C; if shorter than 44 bits it is sign-extended. For
example, If the width is 8, a value of 0x7F means +127 and a value of
0xFF means -1.
Carry in for C (if C is not set to constant)
Table 2-2 lists the Dot Product
17
- 1), while 0x3FFFF
