Vehicle connections

The connection information listed below is specific to the 2010 Mercury Mariner. Refer to "Pre-installation and application warnings" for a list of important notes.
Data harness, 8-pin white connector (H1)
Module
Conn./Pin Color Description
H1/1 Tan (Data) MS CAN Low
H1/2 Tan/Black (Data) MS CAN High
H1/3 Orange/Brown (Data) HS CAN Low
H1/4 Orange/Green (Data) HS CAN High
H1/5 Lt. Green No Connection
H1/6 Violet/Brown No Connection
H1/7 Orange/Black (Data) RX
H1/8 Yellow/Black (Data) TX
Analog input/output harness, 22-pin white connector (H2)
Module
Conn./Pin Color Description
H2/1 Lt. Green/Black (-) Factory Alarm Arm Output
H2/2 Blue/White (-) Ground When Armed (GWA) Output [6]
H2/3 Dk. Green/Black (-) Lock Output [4]
H2/4 Red/White (-) Trunk Hatch Release/Power Liftgate Output
[4]
H2/5 Brown/Black (-) Horn Output
H2/6 Brown/White (-) AUX 1 Output
H2/7 White (+) (+) Accessory Output
H2/8 Violet/Black (+) Starter Output
H2/9 Dk. Blue/Black (-) Unlock Output [4]
H2/10 Lt. Blue/Black (-) Factory Alarm Disarm Output [5]
H2/11 Brown/Red (+) Siren Output [2]
H2/12 Pink (+) Ignition Sense Input
H2/13 Violet (+) Door Input
H2/14 Brown (+) Brake Input
11 933.FORD6 3.20.193 2010 Mercury Mariner
© 2019-01-18 Directed. All rights reserved.
Connects To
Wire Location
OBD-Data Link Connector, black 16 pin plug, pin 11
OBD-Data Link Connector, black 16 pin plug, pin 3
OBD-Data Link Connector, black 16 pin plug, pin 14
OBD-Data Link Connector, black 16 pin plug, pin 6
No Connection
No Connection
PATS Transceiver on ignition switch, black 4 pin plug, pin 4 or
3
PATS Transceiver on ignition switch, black 4 pin plug, pin 3 or
4
Connects To
Wire Location
No Connection
Starter:
Ignition Switch, black 7 pin plug, pin 7
Ignition:
Ignition Switch, black 7 pin plug, pin 1
Must use a relay.
driver kick or SJB on RF side of cntr console, gray 26 pin plg
(C), pin 17
driver kick or SJB, gray 26 pin plug (C), pins 7, 20
Not Applicable
No Connection
No Connection
Ignition Switch, black 7 pin plug, pin 6
Ignition Switch, black 7 pin plug, pin 7
driver kick or SJB on RF side of cntr console, gray 26 pin plug
(C), pin 4
driver kick, door harness
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
Data Violet/Orange (MS CAN) Mandatory
Data Gray/Orange (MS CAN) Mandatory
Data White (HS CAN) Mandatory
Data White/Blue (HS CAN) Mandatory
Data Violet/Gray Mandatory
Data Yellow/Orange Mandatory
(+/-) Wire Color Connection
+ Blue/White Security Only
+ White/Orange
- blue/green Mandatory
- brown (liftgate); brn/yel Mandatory
(glass) (rear handle sw)
+ Violet/Green Remote Start
Only
+ Blue/White Remote Start
Only
- yellow/violet Mandatory
- violet/brown (driver door Mandatory
key unlock)
Security Only
