Directed DS4+ Installation Manual page 6

Wiring diagram with T-Harness (THFON1)
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram (
Ignition Switch
Connector
(connector side)
1
1 2 3 4 5 6 7
2 3
male
female
OBDII Diagnostic
6 933.FORD6 3.20.193 2010 Mercury Mariner
© 2019-01-18 Directed. All rights reserved.
Ignition
Barrel
4 7
5 6
Refer to the Vehicle
connections section for wire
and connector details related
to the standard connections
in the vehicle.
P.A.T.S.
4-pin Connector
(connector side)
THFON1
(optional T-Harness for DS4+ only)
(-) Lock Output: Green/Black
(-) Trunk/Hatch Release/Power Liftgate Output: Red/White
(-) Unlock Output: Blue/Black
(+) Parking Light Output: White
Hood Pin
RAP Off Interrupt: Lt. Green
RAP Off Interrupt: Lt. Green/White
Cut
Driver Door Trigger
(-) Factory Alarm Disarm Output: Lt.Blue/Black
(AC) Tach Input: Violet/White
(+) Siren Output: Brown/Red
Siren
It is IMPORTANT to check that
the fuses are positioned
correctly.
Hood Pin: Gray
).
DS4+ DS4
Proper Fuse
Positioning
DS4
Slide
DS4+
to open
Legend:
Mandatory Connections
Security Only
Remote Start Only
Remote Start + Security
