Directed DS4+ Installation Manual page 12

Module
Conn./Pin Color Description
H2/15 White/Blue (-) Activation (Start Trigger) Input
H2/16 Red/Blue (-) Valet Switch
H2/17 Black/White (-) E-Brake Input
H2/18 Orange/Black (-) Instant Alarm Trigger Input
H2/19 Blue (-) Trunk Trigger Input
H2/20 Green (-) Door Input
H2/21 Gray (-) Hood Switch Input [1]
H2/22 Violet/White (AC) Tach Input
Main harness, 12-pin black connector (H3)
Module
Conn./Pin Color Description
H3/1 Blue/White Relay N.C. No Connection
H3/2 Blue/Red Relay N.O. (+) 12 Volt Input
H3/3 Blue Relay COM (+) Ignition Output
H3/4 White/Brown Relay N.C. No Connection
H3/5 White Relay COM (+) Parking Light Output
H3/6 Red (+) 12 Volt Input
H3/7 Lt. Green/Red Relay N.O. No Connection
H3/8 Lt. Green Relay COM RAP Off Interrupt (conn. side)
H3/9 Lt. Green/White Relay N.C. RAP Off Interrupt (vehicle side)
H3/10 Black (-) Ground
H3/11 White Relay COM (+) Parking Light Output
H3/12 Red (+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
H4/2 Red/Black (+) 12 Volt Input
H4/3 Pink/Black Starter Input (Key Side)
H4/4 Pink/White (+) Flex Relay Output
H4/5 Red (+) 12 Volt Input
12 933.FORD6 3.20.193 2010 Mercury Mariner
© 2019-01-18 Directed. All rights reserved.
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
any fuel injector, 2 pin plug, pin 1
Connects To
Wire Location
No Connection
Ignition Switch, black 7 pin plug, pin 4
Ignition Switch, black 7 pin plug, pin 1
No Connection
driver kick or SJB on RF side of cntr console, blk 32 pin plug
(D), pin 20
Ignition Switch, black 7 pin plug, pin 4
No Connection
driver kick or SJB on RF side of cntr console, gray 26 pin plg
(C), pin 14
driver kick or SJB on RF side of cntr console, gray 26 pin plg
(C), pin 14
driver kick or SJB on RF side of cntr console, blk 32 pin plug
(D), pin 20
Ignition Switch, black 7 pin plug, pin 4
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
(+/-) Wire Color Connection
ac grn/blu, gry/yel, pur/gry, Remote Start
Only
yel/org, brn, or grn/wh
(+/-) Wire Color Connection
+ Blue/Red (20A) Remote Start
Only
+ White/Orange Remote Start
Only
+ violet/white Mandatory
+ Blue/Red (20A) Mandatory
- N.C. green/violet Remote Start
Only
- N.C. green/violet Remote Start
Only
(chassis ground) Mandatory
+ violet/white Mandatory
+ Blue/Red (20A) Mandatory
(+/-) Wire Color Connection
