Vehicle Connections - Directed DB3 Installation Manual

Vehicle connections

The connection information listed below is specific to the 2020 Toyota RAV4 (Smart Key). Refer to "Pre-installation and application warnings" for a list of important notes.
Data 14-pin blue connector (H1)
Module
Conn./Pin Color
H1/1 Light Green
H1/2 Violet/Yellow
H1/3 Tan/Black
H1/4 Tan
H1/5 Orange/Green
H1/6 Orange/Brown
H1/7 Brown
H1/8 Yellow
H1/9 Orange/Yellow
H1/10 Orange/Red
H1/11 Yellow/Red
H1/12 Brown/Red
H1/13 Red
H1/14 Black
Output 12-pin red connector (H2)
Module
Conn./Pin Color
H2/1 Black/White
H2/2 Green/Black
H2/3 Green/White
H2/4 Red/Black
H2/5 Violet/White
H2/6 Gray
H2/7 Gray/Black
H2/8 Violet/Green
H2/9 Violet/Brown
H2/10 Yellow/Black
H2/11 Orange/Black
H2/12 Blue/Red
8 403.TL15 1.15 2020 Toyota RAV4 (Smart Key)
©2023 Directed. All rights
Description
No Connection
No Connection
(DATA) HS CAN High
(DATA) HS CAN Low
No Connection
No Connection
Relay N.O. No Connection
Relay COM. Auto Light Interrupt (Conn. side)
Relay N.C. Auto Light Interrupt (Veh. side)
Relay N.C. No Connection
Relay COM. Ground
[2]
Relay N.O. SLP
(+) 12 Volt Input
(-) Ground
Description
(-) Ground When Running (Status) Input
[3]
(-) PTS Output
(-) Pk light output
(-) Unlock Output
No Connection
(+) Starter Output
No Connection
No Connection
No Connection
No Connection
No Connection
(-) Lock Output
Connects To
Wire Location
No Connection
No Connection
Body ECU on dash fuse box, black 30 pin plug, pin 5
Body ECU on dash fuse box, black 30 pin plug, pin 4
No Connection
No Connection
No Connection
Headlight Switch, white 40 pin plug, pin 5
Headlight Switch, white 40 pin plug, pin 5
No Connection
Steering Lock Actuator on steering column, black 7 pin plug, pin 4
Dash Fuse Box, white 1 pin plug (4L), pin 1
Connects To
Wire Location
Dash Fuse Box, rear, white 56 pin plug (4A), pin 33
OR
Left of Dash Fuse Box, white 20 pin plug (AG4), pin 6
Must use a relay.
Push Start Switch, black 10 pin plug, pin 5
No Connection
Body ECU on dash fuse box, black 21 pin plug, pin 17
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
Body ECU on dash fuse box, black 21 pin plug, pin 18
(+/-) Wire Color
Data Tan
Data Violet
Cut Yellow
Cut Yellow
(chassis ground)
- Tan
+ White (50A)
(chassis ground)
(+/-) Wire Color
Cut Black (w/o Stop-Start System)
Cut Brown (with Stop-Start System)
- Gray
Double Tan (key unlock)
-
- Lt. Green (key lock)
