Installation

Warning! Make sure that the weight of the monitors doesn't exceed the weight
capacity of this product. If you exceed the weight capacity, you might experience
personal injury or damage to the product. This product can support up to 5 kg (11 lb.)
per monitor mount.

Attach the wall plate to the wall

Warning! Wall structures vary, and it is important to make sure that the type of
structure and mounting hardware that you are using will properly support the
mounted equipment. Failure to do so may result in personal injury and/or equipment
damage. The wall should be capable of supporting at least four times the weight of the
mounted equipment.
Warning! The mounting hardware included with this product might not be adequate
for some wall structures. If you lack the necessary expertise to attach this product
to the wall that you are using, contact a construction professional to install the
ARMDUALWALL or to provide specific mounting instructions for your wall.
Note: It may require two people to attach the wall plate to the wall.
1. Position the wall plate where you want to hang the ARMDUALWALL and use the
provided level to make sure that the wall plate is vertical. (figure 1)
figure 1
Level
Wall plate
