Adjust The Armdualwall - StarTech.com ARMDUALWALL User Manual

Adjust the ARMDUALWALL

1. To adjust the position of your monitors, do any of the following:
• To move the monitors up or down in small increments, turn the knobs at the
top of each of the VESA monitor mounts. (figure 16)
• To lock the mounting arms in place, use the hex key to turn the screw in each
of the mounting arms clockwise. (figure 17)
• To increase or decrease the swivel tension, use the hex key to turn the screw in
each of the mounting arms clockwise or counterclockwise. (figure 17)
figure 16
figure 17
Instruction manual
Knob
16
Hex key
