2. Tap the Log Measurements button.
3. Tap a button in the Measure By area to
set the type of measurement interval (time
interval or distance between measurement
positions). Distance is only available when
the GPS is active and acquiring accurate
position data.
4. Tap a field in the Measure Every area to
set the measurement interval.
5. Tap the map to start logging measurements:
For grid maps with an active GPS
receiver, tap the map at any point. The
instrument adds measurement flags to
the map at the current GPS position.
For image maps or for grid maps
without an active GPS receiver, tap
the map at the measurement starting
location. The instrument begins taking
measurements, but does not display
them on the map until measurement
logging is done.
