Tektronix H500 User Manual page 89

Save and load region surveys
A region survey is the set of all defined regions on the current signal, as listed in the Survey Summary tab. You can save region
surveys to a file, and then load a region survey to merge with or replace your current region definitions.
File > Save Survey: saves all defined regions to a system-default file name and location. This function saves the region
definitions only.
File > Save Survey As: saves all defined regions to a specified file name and location. This function saves the region
definitions only.
File > Load Survey: loads a region survey from a file. Follow the on-screen instructions to replace or merge your current
region definitions with those from the file.
File > Load Survey from Results: loads region definitions that are part of a saved signal classification results file (File > Save
Results). Follow the on-screen instructions to replace or merge your current region definitions with those from the file.
File > Export Regions As: writes the current region definitions to a text file in tab-separated or csv file format. See the online
topic Region Import/Export File Format for information on the structure of the text-based region file.
File > Import Regions: loads regions from a tab-separated or csv format file that contains region definitions. If there are
currently defined regions in the instrument, the instrument opens the Load Survey dialog box. Use the dialog box to either
attempt to merge the saved regions with the existing regions, or delete all existing regions before importing the regions.
H500 User Manual
Operating basics
63
