Tektronix H500 User Manual page 121

Table 1: General performance characteristics (cont.)
Frequency Range
Input Level Range
Triggering
Acquisition Mode
Trigger Source
Trigger Types
Trigger Delay
Trigger Position
IF Level Trigger
Trigger Threshold
H500 User Manual
1 MHz up to 20 MHz ± 1 PPM in 1 MHz steps
–15 dBm to +15 dBm, 1 MHz to 15 MHz
–10 dBm to +15 dBm, 16 MHz to 20 MHz
dBm levels assume 50 Ω source
Single or Continuous, Free Run or Triggered
Trigger disabled during Audio Demod, Signal Strength, and DPX measurements
IF Level, External Input, or Internal Timebase
Trigger on rising edge, falling edge, above threshold level, or below threshold level
Range: 0 to 60 seconds
Resolution: 1 μs
Range: 0 to 100%
Resolution: 1%
The IF Level trigger compares the power amplitude of the digitized time-domain data-stream
against the threshold setting.
Range: –160 dBm to +20 dBm
Resolution: 1 dB
Specifications
95
