Figure 7: List Of Active Wlan Connections; Figure 8: Entering A Password For A Wlan Connection - PLUSOPTIX A12C Short Manual

- Touch the button (1) to activate the WLAN interface. The „plusoptiX A12C" or "plusoptiX
A16" then automatically searches for all available networks within its range and displays
these. By touching the down arrow (2), you can view the list.
- Touch the Repeat button (3) to repeat the search for available networks.
Error message:
No WLAN
network set up
- The „plusoptiX A12C" or "plusoptiX A16" only shows password-protected networks. Touch
the relevant entry on the screen to select a wireless network.
Enter
password

Figure 8: Entering a password for a WLAN connection

- Enter the password in the input field and confirm by touching the green checkmark (4) in
the navigation bar. Shortly thereafter, the screen will automatically shut down and the
settings screen will be visible. The „plusoptiX A12C" or "plusoptiX A16" is now connected
with the network and the password for the selected network is saved.
Note:
If a previously saved password is changed, the network must be reselected from
the list and the new password must be entered.
If the Plusoptix device is already connected to a WLAN, a green checkmark (4) will be visible
on the WLAN screen instead of the error message symbol. The name of the WLAN is
highlighted in white and the IP address and host name are shown next to the password (5).
1)

Figure 7: List of active WLAN connections

2) 3)
Seite 8 von 9
4) 5)
