Setting Up The Screen Lock (Only Plusoptix A12C And A16); Figure 4: Setting Up The Screen Lock - PLUSOPTIX A12C Short Manual

4 Setting up the screen lock (only plusoptiX A12C and A16)

To protect the patient data stored in the „plusoptiX A12C" or "plusoptiX A16" from
unauthorised access, the screen can be locked. Touch the lock (1) in the settings.
Activating the screen lock:
- Touch the deactivated button with the lock (2).
- Enter a six-digit PIN using the on-screen keyboard.
- Then touch the green checkmark (3) to activate the screen lock or the red "X" (4) to
discard the entry. As soon as the screen lock is activated, the lock (1) will be seen in the
navigation bar.
Locking the screen:
- Touch the lock (1) in the navigation bar to lock the screen. Once the screen is locked, it
can only be unlocked by entering the six-digit PIN.
Note:
The lock (1) can only be seen in the navigation bar if you have activated the
screen lock in the settings.
Deactivating the screen lock:
- Touch the activated button with the lock (2) and
- Enter your PIN
- Then confirm by touching the green checkmark (3) or the red "X" (4) to discard the entry.

Figure 4: Setting up the screen lock

1) 2) 3)
Seite 6 von 9
4)
