2 Adjusting the basic settings

Touch the button (1) in the settings to access the basic settings.
Selection of the astigmatism display
The astigmatism can be displayed as a plus cylinder or minus cylinder.
Setting the volume
With a 0% setting, the warble sound is turned off.
Setting the screen brightness
Only plusoptiX A12: Screen-Saver-Timer
Time in seconds until the screen switches off after inactivity
Earlier switch-off saves electricity and allows the rechargeable batteries to
last longer. The screen is switched on again after being touched. The
screenshot of the last video image, measurement results and print jobs in
printer spooler are retained when the screen switches off.
Only plusoptiX A12: Automatic shut-off
Time in minutes until the device switches off after inactivity
Earlier shut-off saves electricity and allows the rechargeable batteries to last
longer. The device must be switched on again by pressing the On/Off button.
The screenshot of the last video image, measurement results and print jobs
in printer spooler are deleted when the device switches off.
Only plusoptiX A12C and A16:
Using commas or semi-colons as separators in the CSV files.
The set separator is used for all CSV files that are saved by the Plusoptix
device. Only CSV files that use the set separator can be imported. For more
information, refer to supplementary short manual 5.
Confirm your choice by touching the green checkmark (2) or reject the changes with the red
"X" (3) in the navigation bar.

Figure 2: Basic settings

1) 2) 3)
