5 Setting up the network access via LAN/WLAN (only plusoptiX
A12C and A16)
The "plusoptiX A12C" is equipped with a WLAN interface and the "plusoptiX A16" is
equipped with a LAN and WLAN interface. These interfaces can be used to connect to a
network. The activated LAN or WLAN connection is shown in the header (1)(2).
Note:
WLAN connection with the network can either be set up by entry of a static IP
address, or automatic allocation of the IP address by a DHCP server.
5.1

Setting up a LAN connection (only plusoptiX A16)

Connect the "plusoptiX A16" to your network socket using a LAN cable. No other settings are
needed. The LAN symbol (1) will be shown in the top right of the header on the home page.
To see the IP address and host name of your "plusoptiX A16", open the "Setting up the
network access via LAN / WLAN" page by touching the symbol (2) in the settings.
5.2

Setting up a WLAN connection (only plusoptiX A12C and A16)

The WLAN interface is deactivated in the factory settings. If the WLAN interface is activated,
the LAN interface is automatically deactivated.
Touch the button (2) in the settings to get to this screen.
-

Figure 5: LAN connection (only plusoptiX A16)

Figure 6: Activating WLAN

1)
Seite 7 von 9
2)
IP address
and host name
