Set-up a third schedule to sweep-on the entry lights,
in case they were not manually switched on by a
control station . Note that this schedule simulates a
momentary push button and only turns the lights on .
Name Controls
Schedule 6 Group 4
LCP1:
Group 3
relays 1-7
3 . Provide a button on a control station that
switches on the "entry" lights on the morning
(On Mode) .
4 . Program another button on the same station to
allow the last person out to switch off all lights .
SWITCHES PAGE 1-2
#5: 14 BTN SW 5
#6: ENTRY SWITCH
#7: SWITCH 07
#8: SWITCH 08
SWI ID06-2 ON MODE
EDIT: LCP-1 LOAD-8
LCP1:1-8
A second control station in the managers office can
extend other lighting zones for after hours activities,
such as a photo-shoot, or extended store hours .
Tip: Check out our set-back Thermostats . They can
be locally and remotely programmed through the
Blue Box and can generate a very high Return On
Investment .
Behaviors
On 8:45am
Off 8:46Am
Every Day
Momentary On
Address 6 has
been named
the Entry Switch.
(Refer to Naming
Switches).
Select ON MODE
(refer to Control
Types)
Add LCP 1: 1-7
