THE BLUE BOX LT PROGRAMMING
For more information on groups, please refer to the
Groups FAQ .

PROGRAMMING GROUPS

To Access a Group
Within the DTC, there are two paths you can use to
access a group for programming purposes:
From USER MENU:
1 . Navigate to: USER MENU>GROUP LOADS
and ENTER .
USER MENU
MANUAL OVERRIDE
REVIEW SCHEDULE
GROUP LOADS
PROGRAM SWITCH
SETUP MENU
2 . SCROLL to the correct page . (1 through 6) and
TAB to the desired GROUP . ENTER to begin
editing or creating the desired GROUP .
GROUPS PAGE 1-6
GROUP 1 UNUSED OFF
GROUP 2 UNUSED OFF
GROUP 3 USED MOM
GROUP 4 USED ON
GROUP 5 USED ON
GROUP 6 UNUSED OFF
TAB to a group and SCROLL up or down to change the
status. Enter to edit the group
From the SCHEDULE MENU:
SCHEDULES PAGE 1-6
Name: SCHEDULE 1
SCH 1 ==> NO LOADS
SCH 2 UNUSED
SCH 3 UNUSED
SCH 4 ==> GROUP 4
SCH 5 UNUSED
SCH 6 ==> DISABLED
This group does not
have any loads
Momentary Group
This Group has loads
and is on
Schedule 1 is
programmed and has
no loads
Schedule 3 is not
programmed
Schedule 4 is
programmed and
controls GROUP 4
Schedule 6 is
programmed, but is
disabled
After creating, exiting, and saving a schedule, TAB
DOWN once to NO LOADS, or GROUP X (X
represents a number 1-32) . ENTER to edit or create
the GROUP .
To Edit a Group
1 . SCROLL to select the desired GROUP Type .
GROUP1 MAINTAIN
EDIT: LCP-1 LOAD-1
3 . Add or delete loads .
4 . EXIT when complete .
