MANUAL CONTROL OF RELAYS

Manually control and visually check the (on/off) status
of any relays(s) in any panel(s) .
To Start
1 . TAB once or twice to get started . The USER
MENU will display .
2 . TAB to MANUAL OVERRIDE .
USER MENU
MANUAL OVERRIDE
REVIEW SCHEDULE
GROUP LOADS
PROGRAM SWITCH
SETUP MENU
3 . ENTER to select the MANUAL CONTROL screen .
To Navigate to a LOAD (Relay)
MANUAL CONTROL AU
LCP-1 LOAD-1
1- 3■ 5■ 7■ 9- 11- 13- 15-
2- 4- 6- 8■ 10- 12- 14- 16-
4 . TAB to LCP-1(Lighting Control Panel 1) .
5 . SCROLL to select the correct LCP (for systems
with multiple LCPs) .
6 . TAB to LOAD-1 .
7 . SCROLL up or down to select the LOAD (relay)
to control .
SCROLL to select LCP
TAB to LOAD
SCROLL to select LOAD
ENTER to toggle status
THE BLUE BOX LT PROGRAMMING
To Control a LOAD (Relay):
8 . ENTER to toggle the status of the LOAD "off "
or "on" .
MANUAL CONTROL AU
LCP-1 LOAD-1
1■ 3■ 5■ 7■ 9■ 11- 13- 15■
2- 4- 6- 8■ 10- 12- 14- 16-
- indicates the LOAD is off
■ indicates the LOAD is on
There are other relays statuses . Refer to "Groups
FAQ" for a more complete description of all of the
different relay statuses .
MANUAL CONTROL AU
LCP-1 LOAD-1
1■ 3■ 5■ 7■ 9- 11- 13- 15-
2- 4- 6- 8■ 10- 12- 14- 16-
9 . Press EXIT several times to get back to the main
screen .
LOAD 15 is on. .
LOAD 16 is off.
AU indicates LCP 1 is
in AUTOMATIC mode.
"MN" indicates LCP 1
is in HAND mode
