1 . SCROLL to select LCP (1,2,3, etc . ) .
2 . TAB to LOAD 1 .
3 . SCROLL to the LOAD you want to add or
delete .
4 . ENTER once to add to ON Load Summary .
SWI ID13-1 MIXED MODE
EDIT: LCP-2 LOAD-3
ON LCP1: 1-3
OFF LCP2: 1-3
5 . ENTER twice to add to OFF Load Summary .
6 . ENTER third time to delete LOAD from Load
Summary .
7 . Repeat to add or delete more LOADs .
8 . EXIT up to main menu .
To Delete a Load:
1 . TAB and SCROLL to select LOAD .
2 . ENTER until the LOAD is deleted from the Load
Summary .
SWI ID13-1 TOGGLE
EDIT: LCP-2 LOAD-4
LCP1: 2-5,12
LCP2: 1,4
SWI ID13-1 MIXED MODE
EDIT: LCP-2 LOAD-3
ON LCP1: 1-3
OFF LCP2: 1-3
Mixed Mode
Load Summary
shows LOADS to be
switched ON and
switched OFF
Delete LCP2:4 from
Load Summary
1.TAB to LCP 1
2. SCROLL to LCP 2
3.TAB to LOAD 1
4. SCROLL to LOAD 4
5. ENTER to remove
from Load Summary
Delete "LCP1:3" from
"ON" Load Summary
1.TAB to LOAD 1
2. SCROLL to LOAD 3
5. ENTER until
removed from (ON &
OFF) Load Summary
THE BLUE BOX LT PROGRAMMING
Programming an Occupant Sensor
Once the occupant sensor has been connected to
the low-voltage dry contact inputs in the DI card, the
inputs must be programmed .
Occupant sensor contacts send a "Maintain"
type closure to the inputs on the DI card and are
therefore programmed as a "Maintain" Control Type
(or Maintain Group for more than 8 relays) .
To program a DI Input:
1 . Navigate to the DI card inputs: USER MENU > PRO-
GRAM SWITCH > SWITCH # > BUTTON # .
2 . SCROLL to select MAINTAIN as the Control Type .
SWI ID13-1 MAINTAIN
EDIT: LCP-2 LOAD-5
LCP2: 4,5
3 . Add/delete LOADs (refer to Add or Delete Loads
section) .
If more than 8 relays are added, accept the
creation of a new Group upon EXITing .
To use an existing Group SCROLL to the Control
Type and select the Group .
For more information on Control Types, Groups and
Group types, refer to the relevant sections in the
O&M .
Occupant Sensors
use a MAINTAIN
Control Type
