THE BLUE BOX LT OVERVIEW
GR1416LT DRAWINGS & DETAILS
1 .
Screw fastener secures hinged Control Panel Door (Master only) .
2 .
Hinged Door Panel provides a barrier between Control Interface and High Voltage connections beneath
(Master only) .
3 .
NEMA 1 surface mount enclosure with hinged door and key lock; Ø1/4" mounting holes at 4 places
(hardware not included) .
4 .
DTC Clock / Display & Programming Interface: 32-channel, 365-day astronomical clock with Scroll and Tab
to access control features for entire system (Master only) .
GR1416 LT (FRONT DOOR OPEN)
