THE BLUE BOX LT PROGRAMMING

TIME SCHEDULES

Introduction to Time Schedules
There are a few important things to note before
programming a Time Schedule:
Time Schedules DO NOT control relays – they
control Groups and have Scheduled Events (when
things are on and off) . Groups contain Loads (relays)
and describe "behaviors" pertaining to the schedule .
For more information about groups refer to Groups
Section .
When creating or modifying a schedule .
1 . Scheduled the Events .
2 . Add a group which contains loads (relays) and
their behaviors .
Example:
What it
Name
Controls
Schedule 1 Group 1
LCP1:
relays 1-5
Group 1
LCP2:
relays 3 &
To Navigate to Any Schedule (up to 32).
1 . TAB to start .
2 . TAB to REVIEW SCHEDULE and ENTER to
select .
USER MENU
MANUAL OVERRIDE
REVIEW SCHEDULE
GROUP LOADS
PROGRAM SWITCH
SETUP MENU
3 . A list of the first 6 (of 32) schedules will be
displayed . If needed SCROLL to the correct Page
Its Behaviors
On 9am
Off 5pm
Mon-Fri
When the group is "off ",
relays may only be turned
on for 2 hours (relay-timer)
Prior to shutting lights off,
9
relays issue a blink warning.
SCHEDULES PAGE 1-6
Name: SCHEDULE 1
SCH 1 UNUSED
SCH 2 UNUSED
SCH 3 UNUSED
SCH 4 ===> NO LOADS
SCH 5 UNUSED
SCH 6 UNUSED
4 . TAB to a new or existing SCHEDULE and
ENTER to select .
5 . TAB to EVERY DAY (default) and SCROLL to
select one of three schedule types:
1 . Every Day .
2 . Mon-Fri, Sat Sun .
3 . By Day .
For more information on the three schedule types
refer to Scheduled Types Section .
SCH 1 EXCEPT NONE
EVERY DAY
ON TIME: 09:00 AM
OFF TIME: 05:00 PM
For Every Day or Mon-Fri-Sat-Sun Schedules:
1 . TAB to each ON TIME and OFF TIME .
2 . SCROLL to adjust the Scheduled Event (refer to
"Scheduled Events" Section for more information) .
SCH 1 EXCEPT NONE
EVERY DAY
ON DUSK -30mins
OFF DAWN +30mins
Every Day Schedule - same on & off times 7 days/wk .
SCH 1 EXCEPT NONE
MONDAY - FRIDAY
ON TIME: 09:00 AM
OFF TIME: 05:00 AM
SAT ON TIME: 11:00 AM
OFF TIME: 03:00 PM
SUN none
none
73
Page 1 of 6. SCROLL
to view more pages
"UNUSED" means
sch unprogrammed
"NO LOADS" means
sch is programmed -
no loads assigned
..
SCROLL to adjust
• EVERY DAY
• M-F, S, S
• BY DAY
To Add or to edit
Holiday Lists refer to
Holiday Section
SCROLL to adjust
Scheduled Event
Tab to each Scheduled
Event and SCROLL to
adjust.
