For "By Day" Schedule
With different Scheduled Events for each day of
the week, the "BY DAY" schedule offers the most
comprehensive feature set of all schedule types .
SCH 1
BY DAY H1 H2
Mo Tu We Th Fr Sa Su
ON TIME: 09:00:00a
OFF TIME: 05:00:00p
from Jan 1 to Dec 31
1 . Tab to any day and ENTER to edit that day .
2 . TAB to ON TIME or OFF TIME and SCROLL to
adjust Scheduled Events .
ON TIME: 11:30:00 am
OFF TIME: 02:00:00 pm
ADJUST THESE DAYS:
Mon
every day
To Add Scheduled Events from one day to multiple
days ("By Day" schedules only)
3 . TAB to Every Day (bottom of screen) .
4 . SCROLL and ENTER to select the desired day
or group of days . Repeat until all desired days
are selected . The list of selected days will be
displayed (see below) .
5 . EXIT . Selected days will be updated .
ON TIME: 11:30:00 am
OFF TIME: 02:00:00 pm
ADJUST THESE DAYS:
Mon, Tue, Wed
Thu
6 . Repeat steps 1-5 to edit schedules for other days .
To Select a Start-Date and End-Date
1 . TAB to JAN and SCROLL to adjust .
Monday is highlighted
This is the summary
of Monday's
Scheduled Events
This is the summary
of Monday's
Scheduled Events in
editing mode
This is a list of more
days the Scheduled
Events for Monday
will be copied to
TAB to here. SCROLL
and ENTER to add
days to the above list.
THE BLUE BOX LT PROGRAMMING
2 . TAB to 1 and Scroll to adjust .
3 . Repeat as above to edit the end-date .
4 . EXIT when complete .
SCH 1
BY DAY H1 H2
Mo Tu We Th Fr Sa Su
ON TIME: 09:00:00a
OFF TIME: 05:00:00p
from Sep 1 to Jun 15
Sample Schedules:
SCH 1 EXCEPT NONE
MONDAY - FRIDAY
ON dusk -30 mins
OFF TIME: 01:00 am
SAT dusk -30 mins
OFF TIME: 10:00 pm
SUN NONE
NONE
SCH 1 EXCEPT NONE
EVERY DAY
ON PCEL: 06:00am
OFF PCEL: 09:00am
SCH 2 EXCEPT NONE
EVERY DAY
ON PCEL: 03:00pm
OFF PCEL: 07:00pm
SCH 8
BY DAY H1 H2
Mo Tu We Th Fr Sa Su
ON TIME: 07:00:00a
OFF TIME: 07:00:00p
from Sep 1 to Jun 15
SCH 9
BY DAY H1 H2
Mo Tu We Th Fr Sa Su
ON TIME: 11:00:00a
OFF TIME: 02:00:00p
from jun 16 to aug 31
Edit Schedule start
date and end date
here.
These lights will be
switched on 30 mins
prior to dusk Mon-Sat.
Off time on Saturday
is earlier (10pm).
Lights are off Sunday.
These two schedules
when combined will
control outdoor egress
and parking lighting
before and after
hours for employees
but only when it is
dark out (during the
short daylight hours of
winter.
These two schedules
control lighting at a
school in tandem.
During the school year
(Sept 1 to Jun 15)
lights operate on one
schedule (SCH 8)
During summer break
(Jun 16 to Aug 31),
lights operate on a
much shorter schedule
(SCH 9)
