Build Your System In 3 Steps; Build Your System In 3 Steps - Lighting Controls Blue Box LT Series Installation, Operation & Maintenance Manual

THE BLUE BOX LT OVERVIEW

BUILD YOUR SYSTEM IN 3 STEPS

Every system must have a Master Panel which contains
the clock and photocell inputs and connections for the
optional modem .
STEP 1: MASTER PANEL
How many circuits (relays) do you need to control? (See
pgs . 6-7 for enclosure sizes) .
Do you need a modem for remote dial-up programming?
(See pg . 10, "Modem") .
Do you need inputs for occupant sensors, or contact clo-
sure switches? (See pg . 10, "Digital Input Card")
STEP 2: SLAvE PANELS
For each additional Blue Box
lays) do you need to control? (See pgs . 6-7) .
For each additional Blue Box
puts for occupant sensors, or contact closure switches?
(See pg . 10, "Digital Input Card")
Up to 16 panels and switches may be controlled on the bus .
STEP 3: SWITCHES, OUTDOOR PHOTOCELLS &
ACCESSORIES
How many override switches do you need?
How many buttons on each switch? (1 to 6 buttons cost
the same) .
Will you need a photocell to supplement the DTC astro-
nomical clock? (See pg . 10, "Digital Photocell") .
Add other accessories as shown on pages 10-11 .
Control up to 16 devices .
LT, how many circuits (re-
™
™ LT Series, do you need in-
Each system needs one master panel. Use one Blue Box
for each electric room you are controlling lighting circuits in.
Slave Relay Panel
Slave Relay Panel
Slave Relay Panel
Slave Relay Panel
Chelsea
Digital Switch
17
Master Relay Panel
™
Master Relay Panel
Outdoor Photocell
Master
Relay Panel
