THE BLUE BOX LT PROGRAMMING
To Add Loads to a Schedule
When you have completed programming a time
schedule, the next step is to add the loads to be
controlled .
1 . To save the schedule press EXIT . TAB to "yes"
and ENTER to save the schedule . The clock will
take a second to save the changes and exit back
to the SCHEDULE LIST menu .
2 . TAB to "NO LOADS" and ENTER to add loads
to the schedule .
SCHEDULES PAGE 1-6
Name: SCHEDULE 1
SCH 1 ==> NO LOADS
SCH 2 UNUSED
SCH 3 UNUSED
SCH 4 ==> GROUP 4
SCH 5 UNUSED
SCH 6 ==> DISABLED
3 . TAB to MAINTAIN and SCROLL to choose the
Group Type .
Quick Tip: Choose MAINTAIN for outdoor lighting
and MNTN + BLINK for indoor lighting . For a more
complete understanding of Group Types, refer to the
Group Section later in this manual .
GROUP1 MAINTAIN
EDIT: LCP-2 LOAD-5
LCP1:1-5
LCP2:3,4
4 . TAB to LOAD 1 .
5 . SCROLL to the desired Load (relay) and ENTER
to add to the Load Summary .
6 . Repeat the TAB and SCROLL sequence and add
as many loads as required .
Schedule 1 is
programmed and has
no loads
Schedule 3 is not
programmed
Schedule 4 is
programmed and
controls GROUP 4
Schedule 6 is
programmed, but is
disabled
Choices are
• MAINTAIN
• MNTN + TIMER
• MNTN + BLINK
GROUP1 MAINTAIN
EDIT: LCP-2 LOAD- 5
LCP1:1-5
LCP2:3,4
Additional steps for MAINTAIN + TIMER and
MAINTAIN + BLINK Groups
These steps are considered best practice for indoor
lighting, and include after-hours relay timers .
MAINTAIN groups can EXIT at this point .
7 . With "MNTN + __" highlighted, ENTER to set
advanced options .
8 . TAB to AUTOMATIC ON . SCROLL to change
to NO AUTOMATIC ON if desired . NO
AUTOMATIC ON means lighting will not
automatically be switched on in the morning by
the clock but must be manually switched on by
an occupant . This is considered an energy savings
feature . AUTOMATIC ON will turn the lights
on by the clock, whether occupants are present
or not .
GROUP1 PARAMETERS
AUTOMATIC ON
SET TIMER
9 . TAB to SET TIMER and ENTER to program
the after-hours relay timers . This features allows
occupants to switch lights on after the scheduled
time, but only for a timed duration . This is an
energy savings feature and is required by most
energy codes .
10 . TAB to the Hours/Minutes/Seconds display
and TAB/SCROLL to set the Hours/Minutes
and Seconds of the after-hours timer . 2:00:00 is
usually recommended .
75
LCP1: 1-5 and LCP
3,4 are in the Load
Summary
