Exercise #4 - Retail Store - Lighting Controls Blue Box LT Series Installation, Operation & Maintenance Manual

THE BLUE BOX LT PROGRAMMING
Tip: If you wish to prevent the lights from all coming
on at 7:00 am, select NO AUTOMATIC ON, and then
the local digital switches will turn the lights on and
the schedule will turn the lights off . (see Additional
Group Parameters) This is optimal for energy savings
when local digital switches are used .
GROUP 4 PARAMETERS
NO AUTOMATIC ON
TIMER OUT: 1:00:00 Hr
OFF SWEEP: 05:00 Mins
3 . Program each switch button that will need to
override lighting after-hours with a Toggle or On
Mode control type (refer to Control Types) and
add loads as appropriate .
SWITCHES PAGE 1-2
#5: 14 BTN SW 5
#6: OPEN OFFICE SW1
#7: OPEN OFFCE SW2
#8: RECEPTION
SELECT BTN SW ID#06
PAGE 1-1
B1: BUTTON 1
B2: BUTTON 2
B3: BUTTON 3
B4: BUTTON 4
B5: BUTTON 5
B6: BUTTON 6
SWI ID06-2 ON MODE
EDIT: LCP-1 LOAD-3
LCP1:1,3
Tip: Remember, the smaller the zone of control of
each button the greater the energy savings .

EXERCISE #4 - RETAIL STORE

Information and customer requirements
1 . Store hours: 9:00am to 10:00pm pm every day .
Lights should be swept-on 15 minutes before
store opening and off 20 minutes after closing .
Address 6 has
been named the
OPEN OFFICE
SW1.
Refer to
Navigation Tree
for the Naming
Menus
Select TOGGLE or
ON MODE (refer
to Control Types)
Add any relays in
the group
2 . After-hours, all lights (loads) should be on a
1-hour timer with a 5-minute blink warning .
3 . Employees enter the store as early as 5:00am
and need to switch on enough lights to clean
and stock the store (called the "entry level")
without the complications of a timer .
Entry level lights are controlled by LCP1:1-7 . All
remaining lights are controlled by LCP1:8-24
Programming Steps
For step-by-step instruction on how to program
these schedules, refer to the sections on adding a
load, Control Types, Groups, and time schedules .
1 . Set up a Schedule: ON: 5:00 AM & OFF: 10:20 PM .
Employees coming in any time after 5:00 AM can
switch-on lights manually . The relays will not be
in timer mode because the Group was switched
on at 5:00 AM with NO AUTOMATIC ON .
Name Controls
Group 2
Schedule 4
Entry Lights
LCP1:
Group 2
Relays 1-7
2 . Set up a second schedule: ON: 8:45am &
OFF:10:20pm to sweep-on the remaining loads
15 minutes before and 20 minutes after-hours
Name Controls
Schedule 5 Group 3
LCP1:
Group 3
relays 8-24
89
Behaviors
On 5am
Off 10:20pm
Every Day
Maintain + Blink
NO Automatic On
1 Hour Timer
5 Minute Blink Warn
Behaviors
On 9:20am
Off 10:20pm
Every Day
Maintain + Blink
(Yes) Automatic On
1 Hour Timer
5 Minute Blink Warn
