Troubleshooting

If the Control Head displays alternating VR ERROR and Error Code (RC ERROR XXXX
or RF ERROR XXXX), turn the DVRS off and then back on. If it does not correct the
condition, contact Futurecom to obtain an RMA.
"MAINTENANCE MODE REMOTE DEVICE" on the control head may indicate that the
Mobile Radio Control Head needs to be flash upgraded or that the XTL5000 transceiver
is not powered up.
"INCOMPATIBLE MSU SW" displayed on the control head indicates that the MSU needs
to be flash upgraded to match the firmware currently loaded in the DVR.
VR SYS CH-1-D
Z01 TG_1
VR DISABLED
Z10 TG 1
Z01 TG_1
If DVRS operation is intermittent, check with other DVRS users for similar problems and
try using different PSU and / or channel before contacting a qualified radio technician.
Similar problems indicate a system malfunction or programming issues rather then a
radio failure.
'Warning' 'RC0400' flashing 4 times on Power Up indicates Primary EEPROM Map
corrupted. The unit is fully operation (working from the backup EEPROM map), however
it requires to be serviced. Please bring the unit to your authorized radio shop for service.
Reading the unit with the latest Tweaker version will restore the Primary map from the
backup.
April 2014
NORMAL DISPLAY, DVR ACTIVE:
V R VR SYS [CHAN NAME]
VR LOC [CHAN NAME]
VR OFF [CHAN NAME] (NO DVR ICON)
NORMAL DISPLAY - DVR DISABLED BY
PROGRAMMING
MOBILE MODE SELECTED IS NOT DVR
ENABLED
DVR NOT DETECTED
POSSIBLE CAUSES:
DVR NOT POWERED
CABLE FAULT
DVR FAILURE
