User's Guide

Automatic DVRS Deactivation

AVRA
If the DVR is in the SYSTEM or LOCAL Mode and the AVRA VIP input is de-asserted,
the DVR can be programmed to automatically switch to OFF Mode.
If the DVR is in the OFF Mode, de-asserting the AVRA VIP will not result in any change.
The method of de-asserting the AVRA VIP depends on the actual installed AVRA trigger.
For example, if the selected AVRA trigger is the Portable Charger Switch, de-asserting
the AVRA VIP input is equivalent to placing the PSU back in the charger.
Inactivity Timer
If programmed, the DVR can switch automatically to OFF Mode upon expiration of its
Inactivity Timer (programmable from 0 to 180 minutes). The timer is restarted every time
the DVR detects PSU activity.
