Analog Mode

This Chapter provides details on the DVRS Analog Mode of operation.
The Analog Mode assumes the following:

TM
XTL 5000 MSU with O3 or O5 Programmed for DVRS Operation
TM
OR XTL 2500 MSU with M5 Programmed for DVRS Operation.

PSU programmed for DVRS operation using a Conventional, Analog, non-ASTRO
Personality.

DVR Channel used is programmed for Analog (or Mixed) Mode of Operation.
NOTE:
The basic principles of DVRS operation (both Analog and Digital) are as described in the
DVRS Operation Basics
Analog Mode of operation.
NOTE:
The Local PSU Notation throughout this Chapter refers to a Portable Subscriber Units
using a Conventional Analog DVR Personality.
The System PSU Notation refers to a Portable Subscriber Unit, which is programmed to
communicate directly with the System Infrastructure.
