Conventional Analog PSUs
The DVR in analog mode can be configured to send the following tones to the analog
PSUs:
TONE TYPE
Beep Encrypted Call
Three Short Leading Go
Beeps Ahead
Long Low pitched Leading Deny
tone
Single high- Trailing
pitched tone Successful
System Access
Longer Low Trailing
pitched tone Unsuccessful
System Access
Single Low Low Battery
pitched tone
every 30 seconds
Single Low Trailing -
pitched tone Access Denied
Programmable or Emergency
default (3 short ACK
beeps)
Two short beeps No Activity
Timer
Expiration
Programmable DVR Activation
number of tones,
tone duration and
frequencies.

Table 9 Analog PSU - DVRS Specific Tones

NOTE:
All PSUs which are in the Analog Mode DVR radio coverage area and switched to the
DVR channel will hear the DVR status tones since those are transmitted over the air (on
the same frequency /PL/DPL) and are NOT generated by the portable radios.
