Chapter 3
Prepare the Flight
EVO is factory assembled in the package and features a user-friendly design. It is
possible to open the box, pull out the aircraft and remote controller to experience
LPPHGLDWH ÀLJKW +RZHYHU UHDGLQJ DQG XQGHUVWDQGLQJ WKH IROORZLQJ LQVWUXFWLRQV
and warnings are essential before use, in order to operate safely.

3.1 Prepare the Battery

3.1.1 Install the Aircraft Battery

1.
Power off the aircraft battery before the
installation.
2.
Insert the battery into the aircraft battery
compartment as showing on the right.
7KH EDWWHU\ ZLOO ¿UPO\ FOLFN LQ ZKHQ LW LV
properly installed.

3.1.2 Remove the Aircraft Battery

1.
Power off the aircraft battery before
removal.
2.
Press and hold the top buttoQ
located on the battery and pull it out
slowly.

3.1.3 Charging

The aircraft battery and remote controller can be charged simultaneously using
