To change the gimbal dampener mount on the Autel Robotics Max Series:

1. Remove the gimbal from the aircraft by disconnecting it from the connector at the bottom of the fuselage.
2. Take off the connector cover that fixes the gimbal to the aircraft.
3. Detach the dampeners from the mount supporting the gimbal.
4. Replace the dampeners or mount as needed.
5. Reattach the dampeners to the new or existing mount.
6. Secure the gimbal back onto the aircraft by connecting it to the connector slot and replacing the connector cover.

This process ensures the dampeners continue to buffer vibration effectively.

This answer is automatically generated

Summary of Contents for Autel Robotics EVO Max Series

Page 1 4T/4N Multirotor Aircraft User Manual V1.2 2024.07...
Page 2 Trademark Information , Autel Enterprise trademarks are registered trademarks of ™ the Autel Robotics Co., Ltd. (hereinafter referred to as "Autel Robotics") in China or other countries/regions. Copyright This manual and other documentations mentioned in this manual is copyrighted by Autel Robotics Co., Ltd.
Page 3  IMU: Inertia Measurement Unit Read Before Your First Flight To ensure safe use of the EVO Max series multirotor aircraft, Autel Robotics provides you with the following documents and relevant tutorial videos. Please scan the QR codes in this manual or use the provided links to access them.
Page 4 Getting Tutorial videos, User Documents, and Relevant Software You can scan the QR codes below or visit the following links to access tutorial videos and user documents or download relevant software for the EVO Max series multirotor aircraft: To watch tutorial videos, please visit: https://www.autelrobotics.com/videos/evo-max-series/.
Page 5 Store the aircraft and its accessories out of the reach of children and pets. If you do not abide by the Safety Operation Guidelines, Autel Robotics shall not be responsible for any product damage or personal and property loss during use, and shall not provide any free warranty service.
Page 6 Autel Robotics guarantees users who purchase products through its official authorized channels that:  Under normal use, the Autel Robotics products you purchase will be free from material and workmanship defects during the warranty period.  If you can provide a valid purchase receipt, the warranty period of this product is calculated from the midnight of the next day after you receive the product.
Page 7 Important  All data stored on the product may be erased during the repair process. To avoid data loss, please back up important files in your aircraft or remote controller before the product is under warranty. Update Log The content of this manual will be updated irregularly. The update log is as follows: Version Date Revisions...
Page 8 Compliance with FCC/ISED Any Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Page 9: Table Of Contents
Table of Contents Chapter 1 Product Overview ....................... 1 1.1 Introduction ..........................1 1.2 What's In The Rugged Case....................2 1.3 Product Acceptance Checklist ....................3 1.4 UAS Introduction ........................4 Chapter 2 Flight Safety ........................ 8 2.1 Legal Use Notice ........................8 2.1.1 Chinese Mainland ......................
Page 10 2.12.1 Compass Calibration ....................28 2.12.2 IMU Calibration ......................30 2.12.3 Gimbal Calibration ....................32 2.13 Emergency Stop Propellers During Flight ................ 33 2.14 Remote Identification ......................34 2.15 Standard Flight Operation Process .................. 35 2.15.1 Pre-Flight Checklist ....................35 2.15.2 Basic Flight Process ....................
Page 11 4.1.2 Communication Frequency Bands ................67 4.2 Installing the Remote Controller Lanyard ................. 69 4.3 Installing/Storing Sticks ......................70 4.4 Turning the Remote Controller On/Off ................71 4.5 Checking the Battery Level of the Remote Controller ............. 72 4.6 Charging the Remote Controller ..................73 4.7 Adjusting the Antenna Position of the Remote Controller..........
Page 12 6.2 Main Interface........................103 6.3 Status Notification Bar ....................... 106 6.4 Toolbar..........................107 6.5 “Settings” Interface ......................111 6.6 Attitude Ball ......................... 120 6.7 "Map" Interface ........................121 6.8 Camera Interfaces ....................... 124 6.8.1 Camera Function Access ..................124 6.8.2 Camera Switch and Operation ................128 6.9 Flight Missions ........................
Page 13: Chapter 1 Product Overview
The EVO Max series multirotor aircraft adopts a foldable arm design and can hold its propellers for easy storage and transportation. The aircraft is equipped with a PSDK interface at its top, allowing you to add different industry-specific mounts on the aircraft to meet various operational needs.
Page 14: What's In The Rugged Case
Chapter 1 Product Overview 1.2 What's In The Rugged Case The aircraft is packed and transported in a rugged case (with built-in shock absorption protective materials) and the items inside the case are as follows: Important  Upon receiving the product, please inspect the rugged case in its integrity and confirm that its outer packaging is intact, with no signs of unpacking.
Page 15: Product Acceptance Checklist
After unboxing the product, please check whether the actual items match the items described in the following packing list and carefully inspect the appearance of the aircraft and all accessories. If anything missing or damage is found, please contact Autel Robotics After-Sales Support or authorized dealers promptly.
Page 16: Uas Introduction
Any damage or missing of these components may result in a malfunction. The RTK module is an optional accessory for enhancing aircraft positioning accuracy. Users can contact Autel Robotics to purchase the RTK module based on their needs. Table 1-3 Aircraft Component List...
Page 17 158.4×74.3×50.7 mm EAN: 6924991124412 UPC: 889520204415 Included or Retail Type: Lithium lon Polymer ABX40 Sale. The firmware Rechargeable Battery Autel Robotics Smart Battery version is V0.4.29.1 Capacity: 8070mAh or later. Number of batteries needed for the aircraft: 1. Number of backup batteries: Optional, up to users’...
Page 18  For details about how to install a RTK module, see “3.12 Extension Interface” in Chapter 3.  All the above components have passed Autel Robotics safety and compatibility tests. Users can purchase and use accordingly.  In case of adding any third-party payload before flight, please reasonably evaluate the mounting weight and the gravity center of the aircraft after mounting.
Page 19 Chapter 1 Product Overview have been upgraded to the latest versions before shipment. Users can use accordingly.  When the remote controller and the aircraft are matched in frequency and the remote controller is connected to the internet, the flight application will automatically check for firmware updates.
Page 20: Chapter 2 Flight Safety
Those who fail to implement real-name registration and paste registration marks will be punished by the regulatory authorities in accordance with relevant regulations.  The aircraft is a light unmanned drone. Autel Robotics prohibits youth under the age of 18 from operating this aircraft.
Page 21: The U.s
Chapter 2 Flight Safety Important  According to the regulations outlined in the "Civil Unmanned Aerial Vehicle System Safety Requirements" in Chinese mainland, users are required to input their real-name registration number and Remote ID in the flight application after registration. Additionally, users should enable the Civil Aviation Administration's flight dynamic data reporting function and the aircraft will automatically enable Remote ID broadcast after power-on self-check.
Page 22: The Eu
Chapter 2 Flight Safety 2.1.4 The EU  Drone operators/owners must register with the National Aviation Authority (NAA) of the Member State in which they reside. (https://www.easa.europa.eu/drones/NAA).  This product is not a toy and should not be used by children under the age of 16. ...
Page 23: Flight Environment Requirements
Chapter 2 Flight Safety  Do not fly in areas prohibited by local regulations without authorization. The prohibited areas may include airports, borders, major cities, densely populated areas, large event sites, emergencies (e.g., forest fires), and sensitive building facilities (e.g., nuclear power plants, power stations, transformer stations, prisons, traffic arteries, government buildings, and military facilities).
Page 24: Wireless Communication Requirements
Chapter 2 Flight Safety 2.4 Wireless Communication Requirements  Keep the aircraft at least 200 meters away from areas with strong electromagnetic interference, such as radar stations, microwave stations, and mobile communication base stations.  Keep the aircraft at least 2000 meters away from drone interference equipment. Otherwise, the drone interference equipment and the aircraft cannot work at the same time.
Page 25: Obstacle Avoidance System
Note  When installing a function module to the aircraft, please choose a function module that has passed Autel Robotics safety and compatibility test as this kind of product has already passed flight safety test.  When users are mounting payload, please ensure that the mounting point should be located at the center line of the aircraft and should not be beyond the area bracketed in the left picture in fig 2-1.
Page 26 Chapter 2 Flight Safety Fig 2-2 Front and rear visual obstacle avoidance lens modules of the aircraft Fig 2-3 Top and bottom visual obstacle avoidance lens modules of the aircraft Warning  Do not block the lenses of the visual obstacle avoidance lens during flight, as it will affect the visual obstacle avoidance performance of the aircraft, potentially leading to flight accidents.
Page 27: Observation Range
 Please be noted that the frequency band of the millimeter-wave radar is a hardware parameter, which cannot be adjusted through software. Autel Robotics ensures that the millimeter-wave radar frequency band of the EVO Max series drones complies with local legal regulations.
Page 28: Visual Positioning Function
Chapter 2 Flight Safety the obstacle's ability to reflect electromagnetic waves and its surface size.  The gray area represents the blind spot of a millimeter-wave radar, where the radar cannot detect obstacles.  Observation Range of Radar and Visual Obstacle Avoidance Sensing Systems With the integration of radar and visual obstacle avoidance sensing systems, the aircraft achieves 720°...
Page 29: Visual Obstacle Avoidance Function
Chapter 2 Flight Safety display the following warning prompts: If the takeoff point is inaccurate: The flight application will display a warning "GNSS signal is weak. The landing point may deviate." with a corresponding verbal warning. If GNSS signal is weak: The flight application will show a warning " GNSS signal is weak.
Page 30: Auto-Return
Chapter 2 Flight Safety  Flying over water surfaces or transparent object surfaces.  Flying in environments with rapid and intense changes in lighting or direct exposure to strong light sources.  Flying over extremely dim (with light intensity of less than 15 lux) or extremely bright object surfaces.
Page 31: Manual Auto-Return Activation
Chapter 2 Flight Safety Warning  When the aircraft is in visual positioning mode or attitude mode, the auto-return function cannot be activated.  If the obstacle avoidance behavior is set as “Turn off”, during an auto-return flight, the aircraft will not be able to automatically avoid obstacles. ...
Page 32: Behavior-Based Auto-Return Activation
Chapter 2 Flight Safety return to the home point due to insufficient power.  It is recommended that the aircraft should not enter the critically low battery landing process. Once the critically low battery landing process is initiated, if the landing point does not meet safe landing standards, the aircraft may have no sufficient battery to land in safe place, which may lead to aircraft damage.
Page 33: Auto-Return Obstacle Avoidance Process
Chapter 2 Flight Safety If the current flight altitude is lower than 30 meters, the aircraft ascends to the altitude of 30 meters and 25 meters < Distance from the returns to the home point. home point ≤ 50 meters If the current flight altitude is higher than 30 meters, the aircraft returns to the home point at the current altitude.
Page 34: Rebuilding The C2 Link
Chapter 2 Flight Safety 1. If the landing protection function detects that the ground is suitable for landing, the aircraft will land directly. 2. If the landing protection function detects that the ground is not suitable for landing (e.g., uneven ground or water below), the aircraft will keep hovering, send a prompt in the flight application, and wait for the user to take action.
Page 35: Flight Restrictions And Unlocking Restricted Zones
2.10.1 Geofencing System Autel Robotics has developed a geofencing system for its aircrafts to ensure safe and legal flights. This system can provide real-time updates on airspace restriction information worldwide. In different restricted zones, the flight functions of the aircraft are subject to varying degrees of restrictions.
Page 36: Restricted Zones
Flight restrictions: Aircraft cannot take off or fly in no-fly zones. If you obtain authorization from relevant authorities to fly in a no-fly zone, contact Autel Robotics to request for unlocking the aircraft. Autel...
Page 37 Chapter 2 Flight Safety In the flight application, if you tap on a restricted zone on the map, the following geofencing information will be displayed for this zone:  No-fly Zone: zone name, zone level (no-fly zone), region (prefecture-level city), and no-fly time (visible only for temporary no-fly zones).
Page 38: Ugz Import
Chapter 2 Flight Safety Note  When there is no GNSS signal, if an aircraft accidentally enters a no-fly zone while the aircraft is still locked from the zone, the aircraft will automatically land upon regaining the GNSS signal. During the landing process, the throttle stick will not work, but the user can control the horizontal movement of the aircraft.
Page 39: Altitude And Distance Limits
 Aircraft S/N (Serial number): Multiple serial numbers can be applied at once.  Autel account of UAS operator: Multiple accounts can be applied at once. Log in to the official website of Autel Robotics at www.autelrobotics.com/service/noflight/, enter the relevant information, and complete the waiver application.
Page 40: Aircraft Calibration
Chapter 2 Flight Safety than 120 meters, and in US, it is no more than 400 feet.  When setting the maximum altitude limit, consider whether the RTH altitude set is reasonable or not, which should not exceed the maximum altitude limit. ...
Page 41 Chapter 2 Flight Safety Table 2-4 Compass Calibration Step Operation Diagram After turning on the aircraft and the remote controller, tap " " > “ ” > “ ” > "Compass Calibration" > "Start Calibration" in the main interface of the flight application.
Page 42: Imu Calibration
Chapter 2 Flight Safety Hold the aircraft to keep it with the nose to the left and the side down. Rotate the aircraft 360° horizontally until interface prompts successful calibration.  Please perform the calibration steps according to the tips shown in the compass calibration interface of the flight application.
Page 43 Chapter 2 Flight Safety Table 2-5 IMU Calibration Step Operation Diagram After turning on the aircraft and the remote controller, tap " " > “ ” > “ ” > "IMU Calibration" > "Start Calibration" in the main interface of the flight application.
Page 44: Gimbal Calibration
Chapter 2 Flight Safety Put the left side of the aircraft flat on ground until interface prompts next step. Put the right side of the aircraft flat on the ground until the interface prompts next step. Fold the arms, turn the aircraft nose up, and lay it on the leveled surface until interface...
Page 45: Emergency Stop Propellers During Flight
Chapter 2 Flight Safety If the flight application prompts an alert ”Please calibrate the gimbal motor”, please follow the steps below to calibrate it. Table 2-6 Gimbal Calibration Step Operation Diagram Place the aircraft on a flat ground. After turning on the aircraft and the remote controller, keep the aircraft in a static state.
Page 46: Remote Identification
 If you stop the propellers when the aircraft has an initial velocity, the aircraft will fall along a parabolic trajectory. If the trajectory is unpredictable, do not stop the propellers.  After completing an emergency landing, contact Autel Robotics promptly for a power system inspection and maintenance.
Page 47: Standard Flight Operation Process
Chapter 2 Flight Safety 2.15 Standard Flight Operation Process 2.15.1 Pre-Flight Checklist Before each flight, please follow the steps below to perform a comprehensive pre-flight check to ensure flight safety:  Make sure that the batteries of the aircraft and remote controller are fully charged, and the battery of the aircraft is installed in place, with the unlock button of the battery in a lock state.
Page 48: List Of Safeguard
Chapter 2 Flight Safety  Press and hold the battery power button for 3 seconds to turn on the power of the aircraft, and wait for the rear arm light to turn green and blinks slowly (indicating that the current status is normal). ...
Page 49: Chapter 3 Aircraft
 Make sure that the remote controller is connected to the Internet before starting the activation process. Otherwise, activation may fail.  If activation fails, please contact Autel Robotics After-Sales Support for assistance.  For how to match the aircraft with the remote controller in frequency, see “4.9 Frequency...
Page 50 Chapter 3 Aircraft the fuselage. Forward Visual Obstacle Used to sense the obstacles ahead and avoid the aircraft from Avoidance Sensing colliding with them. Lens Group Integrates multiple sensors stable shooting Gimbal Camera measurements during flight. Fig 3-2 Aircraft Rear View Table 3-2 Aircraft Rear View Details Name Description...
Page 51 Chapter 3 Aircraft Warning  The USB-C interface of the aircraft cannot be used for charging. Do not connect the included remote controller charger. For how to charge the aircraft, see “5.3.5 Charging the Smart Battery” in Chapter 5. Fig 3-3 Aircraft Top-Down View Table 3-3 Aircraft Top-Down View Details Name Description...
Page 52 Chapter 3 Aircraft Fig 3-4 Aircraft Bottom-Up View Table 3-4 Aircraft Bottom-Up View Details Name Description Downward Visual Obstacle Used to sense obstacles below, and to the left and right of the Avoidance Lens aircraft and avoid collisions. Group An LED auxiliary light. In weak light conditions, it is used to enhance the ambient brightness of the landing area during the Auxiliary Light landing...
Page 53: Propeller
 Propellers cannot be installed on the wrong propeller mounts. Please carefully distinguish between propellers and mounts.  Autel Robotics provides two spare propellers for each aircraft (with models 1158CW and 1158CCW respectively). Please refer to the “Packing List” and packaging for details.
Page 54  Before each flight, make sure that all propellers are mounted correctly and securely.  Please use the propellers provided by Autel Robotics. Do not mix propellers of different models.
Page 55: Storing Propellers
Chapter 3 Aircraft 3.3.2 Storing Propellers After using the aircraft, fold the arms as shown below and store the propellers in the rugged case. Fig 3-6 Store the Propellers 3.4 Arm Light There is an LED indicator at the end of each arm of the aircraft. After the aircraft takes off, the front arm lights will blink periodically, which can help you identify the direction of the aircraft's nose;...
Page 56: Strobe
Chapter 3 Aircraft Table 3-7 Rear Arm Light Status Details Indicator Status Definition (R: Red G: Green Y: Yellow) Normal R– Ultra-fast Blinking /Fast Blinking System Self-Test →Y- Fast Blinking Compass/IMU Calibration Y– Slow Blinking Start Calibration G– Slow Blinking Current Step Calibration Successful G–...
Page 57: Auxiliary Bottom Light
Chapter 3 Aircraft Fig 3-8 Strobe  For how to turn the strobe on or off, see “6.4 Toolbar” and “6.5 “Settings” Interface” in Chapter 6. Warning  Do not look directly at the strobe while they are on to avoid vision damage caused by strong light.
Page 58: Gimbal Camera
Chapter 3 Aircraft  For how to turn the auxiliary bottom lights on or off, see “6.4 Toolbar” and “6.5 “Settings” Interface” in Chapter 6. Warning  When the auxiliary bottom lights are set to auto mode, they will turn on automatically at an altitude of around 5 meters above the ground when the aircraft is landing and the ambient light is insufficient, and they will turn off automatically after successful landing.
Page 59: Camera Operations
Chapter 3 Aircraft measuring the time from the beginning of the laser emission to the time when the laser is reflected from the target. Measuring range: 5-1200 meters. The infrared thermal imaging camera is used for radiometric measurement and night vision, which can monitor the Infrared Thermal temperature distribution of the measured target in real time, so Imaging Camera...
Page 60: Aircraft Gimbal
Chapter 3 Aircraft Components” in Chapter 4.  Control Camera in the Flight Application For details about how to control the camera in the flight application, see “6.8 Camera Interfaces” in Chapter 6. 3.8 Aircraft Gimbal The aircraft is equipped with a three-axis stabilized gimbal with a high-precision motor structure, which can ensure stable camera shooting when the aircraft is flying.
Page 61: Gimbal Mechanical Rotation Range
Chapter 3 Aircraft Used to control the moving range of the gimbal to roll left or Roll Axis Motor right (mechanical range of Fusion 4T: -45° ~ +45°; mechanical range of Fusion 4N: -50° ~ +50°). Used to control the moving range of the gimbal to rotate left or Yaw Axis Motor right with its own axis (mechanical range: -45°...
Page 62: Replacing The Gimbal
 Do not replace the gimbal frequently. The gimbal connector is a precision element, and frequent plugging and unplugging may result in poor contact between the aircraft and the gimbal.  Please use the gimbal model specified by Autel Robotics for replacement. Incompatible gimbals may cause damage to the aircraft. Warning ...
Page 63 Chapter 3 Aircraft before removing or installing the gimbal, so as to prevent the mount from being damaged.  Removing the Gimbal 1. Press and hold the power button of the smart battery for 3 seconds to turn it off and remove the smart battery.
Page 64: Flight Control System
Chapter 3 Aircraft Fig 3-14 Mounting the Gimbal Important  Please make sure that the connector cover of the gimbal camera is aligned with the connector slot at the bottom of the fuselage, otherwise, it will affect the connection between the gimbal and the aircraft. Warning ...
Page 65: Flight Status
Chapter 3 Aircraft Provides the aircraft with all-day and all-weather obstacle Millimeter Wave Radar avoidance sensing capability. 3.9.1 Flight Status Depending on the availability of GNSS signals and flight conditions, the aircraft can automatically switch between the following three modes. Users can check the flight status of the aircraft in the status notification bar in the flight application.
Page 66: Flight Modes
Chapter 3 Aircraft 3.9.2 Flight Modes The aircraft has varying flight power output performance in different flight modes. You can set the flight mode of the aircraft in the flight application. For more information, see “6.3 Status Notification Bar” and “6.5 “Settings”...
Page 67: Hot Swap Battery
Chapter 3 Aircraft  Intelligent Obstacle Avoidance The intelligent obstacle avoidance function uses the combined observation results of the visual obstacle avoidance sensing system and the forward millimeter-wave radar sensing system of the aircraft to calculate the optimal flight path, achieving obstacle avoidance in multiple directions.
Page 68: Connecting To Pc/Mac
Chapter 3 Aircraft Fig 3-15 Installing the microSD Card  The aircraft has built-in 128 GB storage space, with approximately 64 GB available due to storage of system firmware upgrade.  It is recommended that you prioritize using an external microSD card for storing the image data collected during flight to avoid running out of internal storage space, which will affect the flight safety of the aircraft.
Page 69: Extension Interface
Important  Mounts for the aircraft are sold separately. If you need a mount, contact Autel Robotics or third parties that have passed safety and compatibility certification test.  Do not plug a device that uses other USB-C interface standards into the PSDK extension interface, as it may damage the aircraft.
Page 70: Protection Rating
Chapter 3 Aircraft  When the aircraft is fully charged and is equipped with the RTK module, the hovering time will be extended to 37 minutes, and other aspects are not affected. 3.13 Protection Rating Under controlled laboratory conditions, the aircraft (with smart batteries installed) can achieve an IP43 protection rating following IEC 60529 standards.
Page 71: Aircraft Communication Frequency Bands
Chapter 3 Aircraft Fig 3-17 A-weighted sound power level of the aircraft  A-weighted sound pressure level Measurement results for the aircraft, in accordance with the requirements of GB 42590-2023 in Chinese mainland, are provided below: Table 3-14 Noise Measurements Results (normalized to 1 m from the aircraft) Observation Points Hover Fly (1 m/s)
Page 72 Chapter 3 Aircraft  Both data link path transmission and data storage adopt the AES-256 encryption method to ensure the communication data security between end-to-end. Note  The transmission data is based on the ground control station and comes from test data, and the test environment and conditions are different, and the data may be different.
Page 73 Chapter 3 Aircraft  Canada (ISED)  EU (CE)  UK (UKCA)  USA (FCC) 5.2G 5150-5250MHz  EU (Except Germany, CE)  UK (UKCA) 5.2G 5170-5250MHz  Germany (CE) 5.8G 5725-5829MHz  Chinese Mainland (SRRC)  USA (FCC)  Canada (ISED) 5.8G 5725-5850MHz ...
Page 74 Autel Robotics Autel Integrated Command Control Software Autel Enterprise System Software Version V1.0.0.0 or higher V1.0.0.0 or higher Requirement Supplementary Standard configuration Nest Kit Information  The remote controller is a standard accessory in the aircraft package, and Autel Robotics...
Page 75 Chapter 3 Aircraft also provide retail package to choose separately.  When using the above devices to remotely control the aircraft, make sure that the software version meets the above requirements.
Page 76: Chapter 4 Remote Controller
Chapter 4 Remote Controller Chapter 4 Remote Controller 4.1 Introduction The remote controller is installed with the flight application Autel Enterprise by default, allowing you to operate and set the aircraft and the gimbal camera and transmit high- definition videos from the gimbal camera in real time. It offers a maximum communication distance of 15 kilometers.
Page 77 Chapter 4 Remote Controller Video Recording Press the button to start recording video and press it again to Button end recording video. Customize the key function in the flight application. For more Key C1 information, see “6.5 “Settings” Interface” in Chapter 6. For heat dissipation of the remote controller.
Page 78 Chapter 4 Remote Controller Fig 4-2 Remote Controller Front View Table 4-2 Remote Controller Front View Details Name Description Transmits the control signals of the remote controller to the Antenna aircraft and receives the image transmission information from the aircraft. Battery Level Displays the remaining battery level of the remote controller.
Page 79: Communication Frequency Bands
Chapter 4 Remote Controller Fig 4-3 Remote Controller Rear View Table 4-3 Remote Controller Rear View Details Name Description Speaker Plays sound to indicate the status of the device. Used to prevent external damage such as collision and Protective Cover abrasion to the remote controller.
Page 80 Chapter 4 Remote Controller  In actual use, after the aircraft and the remote controller is turned on and matched in frequency, the flight application in the remote controller will automatically determine and select the radio communication frequency band that complies with local regulations for the specific country or region based on the GNSS information received by the aircraft.
Page 81: Installing The Remote Controller Lanyard
Chapter 4 Remote Controller  UK (UKCA) 5.8G 802.11a/n/ac  Chinese Mainland (SRRC) （5725-5829MHz）  USA (FCC) 5.8G  Canada (ISED) 802.11a/n/ac （5725-5850MHz）  EU (CE)  UK (UKCA) Note  Some countries and regions have strict restrictions on the use of radio communication frequency bands.
Page 82: Installing/Storing Sticks
Chapter 4 Remote Controller Fig 4-4 Install the Remote Controller Lanyard (As Required) 4.3 Installing/Storing Sticks The remote controller features removable sticks, which effectively reduce storage space and enable easy carrying and transportation.  Installing sticks There are stick storage slots above the mental handle at the back of the controller. Rotate counterclockwise to remove the two sticks and then rotate them clockwise to install them separately on the remote controller.
Page 83: Turning The Remote Controller On/Off
Chapter 4 Remote Controller unintended startup of the aircraft. 4.4 Turning the Remote Controller On/Off  Turning the Remote Controller On Press and hold the power button at the top of the remote controller for 3 seconds until the controller emits a "beep" sound to turn it on. Fig 4-6 Turning the Remote Controller On ...
Page 84: Checking The Battery Level Of The Remote Controller
Chapter 4 Remote Controller Fig 4-7 Turning the Remote Controller Off  When the remote controller is on, you can press and hold the power button at the top of the remote controller for 6 seconds to forcibly turn it off. 4.5 Checking the Battery Level of the Remote Controller When the remote controller is off, short press the power button of the remote controller for 1 second, and the battery level indicator will display the battery level of the remote controller.
Page 85: Charging The Remote Controller
AC power supply (100-240 V~ 50/60 Hz). Fig 4-9 Use the remote controller charger to charge the remote controller Warning  Please use the official charger provided by Autel Robotics to charge the remote controller. Using third-party chargers may damage the battery of the remote controller.
Page 86: Adjusting The Antenna Position Of The Remote Controller
Chapter 4 Remote Controller  After charging is complete, please disconnect the remote controller from the charger promptly. Note  It is recommended to fully charge the remote controller battery before the aircraft takes off.  Generally, it takes about 120 minutes to fully charge the aircraft battery, but the charging time is related to the remaining battery level.
Page 87: Remote Controller System Interfaces
Chapter 4 Remote Controller Fig 4-10 Extend the antenna 4.8 Remote Controller System Interfaces 4.8.1 Remote Controller Main Interface After the remote controller is turned on, it enters the main interface of the flight application by default. In the main interface of the flight application, slide down from the top of the touch screen or slide up from the bottom of the touch screen to display the system status notification bar and navigation keys, and tap the "Home"...
Page 88 Chapter 4 Remote Controller Fig 4-11 Remote Controller Main Interface Table 4-7 Remote Controller Main Interface Details Name Description Time Indicates the current system time. Battery Status Indicates the current battery status of the remote controller. Indicates that location information is currently enabled. If not enabled, the icon is not displayed.
Page 89 Chapter 4 Remote Controller close the application. Select the interface where you want to take a screenshot, and tap the "Screenshot" button to print, transfer via Bluetooth, or edit the screenshot. The app is installed in the system by default. Tap it to manage Files the files saved in the current system.
Page 90: Pull-Down Shortcut Menu
Chapter 4 Remote Controller Maxitools √ 2.45 Android 11 Google Pinyin √ 4.5.2.193126728-arm64-v8a Android 11 Input Android √ Android 11 Keyboard (AOSP)  Please be aware that the factory version of the flight application may vary depending on subsequent function upgrades. 4.8.2 Pull-Down Shortcut Menu Slide down from anywhere on the "Remote Controller Interface", or slide down from the top of the screen in any app to display the system status notification bar, and then slide down again...
Page 91: Frequency Matching Between The Aircraft And The Remote Controller
Chapter 4 Remote Controller remote controller. Tap the “ ” icon to enable or disable the Wi-Fi function. Press Wi-Fi and hold it to enter WLAN settings and select the wireless network to be connected. Tap the “ ” icon to enable or disable the Bluetooth function. Bluetooth Press and hold it to enter the Bluetooth settings and select the Bluetooth to be connected.
Page 92 Chapter 4 Remote Controller is required after the aircraft is powered on. Normally, after completing the aircraft activation process, users can directly use the remote controller to operate the aircraft.  If the aircraft and the remote controller become unmatched due to other reasons, please follow the above steps to match the aircraft with the remote controller in frequency again.
Page 93: Selecting Stick Mode
Chapter 4 Remote Controller  The firmware of the smart battery should be V0.4.29.1 or later so that the multi-aircraft matching can be supported. Otherwise the matching cannot be triggered. When you use a smart battery with a version lower than that one, please connect the RC through Single Link, reboot the RC and the aircraft and upgrade them by following instructions in the interface.
Page 94 Chapter 4 Remote Controller  Mode 1 Fig 4-13 Mode 1 Table 4-10 Mode 1 Details Stick Move Up/Down Move Left/Right Controls the forward and backward Left Stick Controls the heading of the aircraft movement of the aircraft Controls the ascent and descent of Controls the left or right movement Right Stick the aircraft...
Page 95: Setting Stick Mode
Chapter 4 Remote Controller  Mode 3 Fig 4-15 Mode 3 Table 4-12 Mode 3 Details Stick Move Up/Down Move Left/Right Controls the forward and backward Controls the left or right movement Left Stick movement of the aircraft of the aircraft Controls the ascent and descent of Right Stick Controls the heading of the aircraft...
Page 96 Chapter 4 Remote Controller Table 4-13 Default Control Mode (Mode 2) Mode 2 Aircraft Flight Status Control Method Left Command 1. The up-and-down direction of the left Stick stick is the throttle stick, which is used to Move Up or control the vertical lift of the aircraft.
Page 97: Starting/Stopping The Aircraft Motor
Chapter 4 Remote Controller Right Stick 1. The left-and-right direction of the right Move Left or stick is the roll stick, which is used to Right control the flight of the aircraft in the left and right directions. 2. Push the stick to the left, and the aircraft will tilt to the left and fly to the left of the nose;...
Page 98: Remote Controller Keys
Chapter 4 Remote Controller sticks inward or outward, as shown in the figure, until the power motor stops. Warning  When the aircraft is taking off and landing, keep it away from people, vehicles, and other moving objects.  In flight, the aircraft will initiate a forced landing in case of sensor anomalies or critically low battery level.
Page 99: Take-Off/Return-To-Home Button And Pause Button
Chapter 4 Remote Controller  Gimbal Pitch Down: The heading angle of the gimbal returns from the current position to be consistent with the heading of the aircraft nose, and the gimbal pitch angle rotates to 90° direction from the current angle. Map/Image Press to trigger: switch between the map full screen display Transmission...
Page 100: Turning On/Off The Remote Controller Prompt Sound
Chapter 4 Remote Controller Fig 4-17 Take-off/Return-to-Home Button and Pause Button  When the aircraft pauses an auto-return, it will hover in place. To resume the auto-return, press the pause button “ ” again until the remote controller emits a "beep" sound. Warning ...
Page 101: Calibrating The Remote Controller
Chapter 4 Remote Controller 1. Make sure the aircraft is powered on. 2. In the main interface of the flight application, tap “ ” >” ”>” ”->”Compass calibration of remote controller”, and enter the calibration interface. 3. Tap “Start calibrating” button, hold the RC, and perform an 8-figure notion as shown in the picture on the interface until the RC emits calibration result sound.
Page 102: Hdmi Screen Output
Chapter 4 Remote Controller Calibration dials command sticks: According to the instructions calibration interface, move the left and right dial wheels and the left and right sticks according to the directions shown in the figure and hold for 1 second. At this time, a beep will be heard, and the calibration direction icon will be changed from gray to dark blue,...
Page 103: Chapter 5 Smart Battery
Chapter 5 Smart Battery Chapter 5 Smart Battery 5.1 Battery Introduction The aircraft comes standard with ABX40 or ABX41 smart battery (both hereafter referred to as smart battery) as the power battery. As power battery, they both are rechargeable lithium-ion polymer (LiPo) battery and feature high energy density and capacity.
Page 104: Smart Battery Functions
Chapter 5 Smart Battery 5.2 Smart Battery Functions The smart battery has the following functions:  Battery Level Display The smart battery has a built-in battery level indicator, which shows the current battery level of the smart battery.  Self-heating This function allows the smart battery to operate normally even in low-temperature environments, ensuring flight safety.
Page 105: Smart Battery Usage
Chapter 5 Smart Battery  Overcharge Protection Charging will stop automatically when the smart battery is fully charged, as overcharging can severely damage the battery.  Balance Protection The voltage of each battery cell in the smart battery is automatically kept balanced to protect the battery and maximize the performance of the battery.
Page 106: Installing/Removing The Smart Battery
Chapter 5 Smart Battery 5.3.1 Installing/Removing the Smart Battery Table 5-2 Install the Smart Battery Step Operation Diagram Turn off the smart battery before installing the battery. Slowly insert the smart battery into the battery compartment on the aircraft fuselage, and you will hear a clicking sound when the battery is in place.
Page 107: Turning On/Off The Smart Battery
Chapter 5 Smart Battery 5.3.2 Turning On/Off the Smart Battery  Turning On the Smart Battery When the smart battery is turned off, press and hold the power button for 3 seconds to turn on the battery.  Turning Off the Smart Battery When the smart battery is turned on, press and hold the power button for 3 seconds to turn off the battery.
Page 108: Smart Battery Self-Heating
Chapter 5 Smart Battery Fig 5-3 Checking Battery Level When the Smart Battery is Off Table 5-4 Battery Level Indicator Status (While Not Charging) : Green light is always on : Green light blinking : Off  After the aircraft is connected to the remote controller, you can check the current smart battery level of the aircraft in the top status notification bar or on the "Battery Information"...
Page 109 Chapter 5 Smart Battery  If the smart battery is not installed in the aircraft, short press the power button for 1 second and then press and hold the power button for 3 seconds to activate the battery self-heating function to keep the battery temperature between 15°C and 20°C for 10 minutes. At this point, if you want to exit the battery self-heating function, short press the power button for 1 second, and then press and hold the power button for 3 seconds.
Page 110: Charging The Smart Battery
Chapter 5 Smart Battery aircraft will not be allowed to take off. It is recommended to wait until the self-heating is over or the battery naturally cools down to an appropriate temperature before operating.  When the temperature of the smart battery is lower than 5°C, the internal resistance of the battery will increase and the voltage will drop suddenly due to the low temperature, which will reduce the usable capacity of the battery and reduce the operating time of the aircraft.
Page 111  Modifying the official smart battery or charging device provided by Autel Robotics is prohibited.  Only use the battery and charging device provided by Autel Robotics. Autel Robotics is not responsible for any consequences, such as battery accidents and flight failure, caused by the use of third-party batteries or charging devices.
Page 112: Storing And Transporting The Smart Battery
Chapter 5 Smart Battery during battery discharge. : Indicator light blinking : Off 5.4 Storing and Transporting the Smart Battery When storing the smart battery, keep the battery away from water or heat sources and store it in a dry, well-ventilated environment at room temperature. Ideal storage conditions: The battery level is at around 60%, the ambient temperature is between 22°C to 28°C, and the ambient humidity is 65%±20% RH.
Page 113: Maintaining And Handling The Smart Battery
Chapter 5 Smart Battery 5.5 Maintaining and Handling the Smart Battery 5.5.1 Maintaining the Smart Battery In order to maintain the activity of the smart battery of the aircraft, it is recommended to perform battery maintenance if any of the following conditions are met: ...
Page 114: Recycling The Smart Battery
Chapter 5 Smart Battery 5.5.4 Recycling the Smart Battery  If the smart battery is discarded due to damage, leakage, or other issues that compromise the integrity of the battery shell, it is recommended to completely immerse the battery in an insulated bucket filled with 5% salt water for more than 48 hours until the battery is completely discharged.
Page 115: Chapter 6 Flight Application
Chapter 6 Flight Application 6.1 Software Introduction The flight application is a flight control software developed by Autel Robotics for enterprise applications. The software integrates waypoint mission, polygon mission and other mission modes and is easy to quickly get started. The latest version (V2.1.119 and higher versions) supports Single Link and A-Mesh Link modes.
Page 116 Chapter 6 Flight Application Table 6-1 Details of the Main Interface of the flight application Name Description For details about the status notification bar, please refer to “6.3 Status Notification Bar” in this chapter. In Single Link: It displays the aircraft system’s alarm notification and ...
Page 117 Chapter 6 Flight Application  The flight application can automatically identify the gimbal camera model mounted on the aircraft and adjust the display content of the main interface accordingly. When an aircraft with a different gimbal camera model is connected to the remote controller, the display content on the main interface of the flight application may vary.
Page 118: Status Notification Bar
Chapter 6 Flight Application  In any camera full-screen interface or camera split-screen interface, you can swipe up anywhere to hide all function icons and swipe down to restore the display of function icons. 6.3 Status Notification Bar Fig 6-2 Status Notification Bar of the flight application Table 6-3 Details of the Status Notification Bar of the flight application Icon Meaning...
Page 119: Toolbar
Chapter 6 Flight Application controller signal is displayed as weak. 3. When the remote controller is not connected to the aircraft, the remote controller signal is displayed in gray color. After a RTK module is installed on the aircraft, it RTK Signal Status displays the RTK signal status and positioning accuracy level of the aircraft.
Page 120 Chapter 6 Flight Application hardware support and unavailable functions will be displayed in grey.  When all aircrafts are selected (“ALL” selected), some functions will be displayed in grey and be unavailable. Fig 6-3 Toolbar Table 6-4 Toolbar Details Icon Name Description Tap this icon to enter the “Shortcuts”, where you...
Page 121 Chapter 6 Flight Application lights, strobes, and auxiliary bottom lights after users sign the disclaimer. Tap this icon to open function panel of the aircraft Payload payload. Tap this icon to turn on the bottom auxiliary light, which is used to improve the environment lightness Aux Light when the aircraft is landing in a dark light environment.
Page 122 Chapter 6 Flight Application editing interface. Tap this icon to enter the “Missions” interface, Mission where you can query, edit, favorite, and delete previously saved historical flight missions. Tap this icon to configure the remote controller to Stitch connect to a computer device with 2D/3D mapping software installed, which allows for fast mapping.
Page 123: Settings" Interface
Robotics cloud service account. Tap this icon to query the flight logs of the aircraft. To use this function, you need to log in to your Autel Robotics cloud service account. Tap this icon to set a security password for Encrypt encrypting captured media materials.
Page 124 Chapter 6 Flight Application  Tap “ ” icon at the upper right corner of the quick setting panel to fold this panel  Tap “ ” icon at the lower right corner of the quick setting panel to enter the mesh network settings interface (“my team”...
Page 125 Chapter 6 Flight Application Turn On/Off Distance Limit Tap the button on the right side of "Distance Limit" to turn on or off the distance limit function.  If this function is turned on, enter the distance limit value in the edit box of "Distance Limit (20-5000m)"...
Page 126 Chapter 6 Flight Application  Appropriate altitude limit and distance limit settings can improve flight safety.  The altitude limit should not be set lower than the RTH altitude value. The altitude limit setting should comply with local (within the flight operation area) laws and regulations. Flying the aircraft in an unsuitable flight altitude may have legal risks.
Page 127 Chapter 6 Flight Application  When the aircraft performs automatic missions (such as automatic return, waypoint missions, and polygon missions), the aircraft's collision avoidance behavior will be "Turn off" or "Bypass" by following the setting (when the collision avoidance behavior is set to "Emergency stop"...
Page 128 Chapter 6 Flight Application 3. Set Split Screen Effect  Uniform Scale: In dual-screen mode, the image transmission screen is proportionally reduced.  Fit the screen: In dual-screen mode, the image transmission screen is stretched to cover the screen.  Image Transmission Mode: “Smooth” means 720P and "HD" means 1080P. ...
Page 129 Chapter 6 Flight Application 2. Turn On/Off Extended Pitch Angle  If this function is turned on, the gimbal can rotate up to 30 degrees above the level baseline.  If this function is turned off, the gimbal can only maintain a level or downward rotation and cannot rotate upwards to switch to a pitch view.
Page 130 Chapter 6 Flight Application account. 4. Check RTK Coordinate System After completing RTK network connection, you can view coordinate system type, RTK positioning method, latitude and longitude, altitude, satellite searching number and mean in the RTK coordinate system. Note  Before enabling network RTK service, please connect the RC or the aircraft to the internet. ...
Page 131 Please stay away from crowds or buildings when using this function.  After the "Emergency Stop Propellers During Flight" function is enabled, please stop using the aircraft and contact Autel Robotics to inspect the power system of the aircraft.
Page 132: Attitude Ball
Chapter 6 Flight Application  The auxiliary bottom light is mainly used to enhance the ambient brightness of the landing point during the landing of the aircraft, improve the sensing performance of the downward visual obstacle avoidance sensing system, and ensure landing safety. ...
Page 133: Map" Interface
Chapter 6 Flight Application Displays the current nose orientation of the aircraft. If the aircraft is no longer visible in the line of sight, the aircraft can Aircraft Heading be controlled to return to the home point based on the position and heading of the aircraft.
Page 134 Chapter 6 Flight Application Fig 6-7 "Map" Interface Table 6-6 Interface Button Details Icon Name Description When the remote controller is connected to the Internet, tap this icon and enter POI or latitude and Search Map longitude. According to what you enter, the “Map” interface will switch...
Page 135 Chapter 6 Flight Application This icon indicates that the display direction of the map is unlocked. When the remote controller is rotated, the display Orientation Unlock direction of the map will change accordingly. Tap this icon to lock the display direction of the map of the current remote controller.
Page 136: Camera Interfaces
Chapter 6 Flight Application 6.8 Camera Interfaces 6.8.1 Camera Function Access Fig 6-8 Camera Function Access Table 6-7 Camera Menu Details Icon Meaning Description Switch to Zoom On any camera full screen interface, tap this icon to Camera enter the zoom camera interface. Switch to Thermal On any camera full screen interface, tap this icon to Camera...
Page 137 Chapter 6 Flight Application Video Tap this icon to start/end recording. Tap this icon to view photos and videos from the Album aircraft's album and the local album and download or delete them. Zoom Camera On the "Zoom Camera" interface, tap this dynamic Zoom icon to adjust the zoom factor of the zoom camera.
Page 138 Chapter 6 Flight Application horizontal direction.  Camera Settings On any camera interface, tap the " " icon to enter the "Camera Settings" interface. On the “Camera Settings” interface, you can perform the following operations: 1. View Photo Properties Tap the " "...
Page 139 Chapter 6 Flight Application  Select Camera Tap "Select Camera" to select the lens used for shooting from the list of lenses of the gimbal camera. You can select one or more lenses.  After a shooting lens is selected, when you tap the " "...
Page 140: Camera Switch And Operation
Chapter 6 Flight Application  The pre-recording function can prevent missing important shots when the aircraft is flying rapidly. 6.8.2 Camera Switch and Operation  Camera Switch In the flight application, tap the " " icon in the corner of the "Zoom Camera" preview ...
Page 141 Chapter 6 Flight Application  After selection, the images from the thermal camera will be displayed in the color style of the selected color palette. 2. Set Infrared Shooting Tap the " " icon to enter the "Camera Settings" interface and perform relevant settings. For more information, see “6.8.1 Camera Function Access”...
Page 142: Flight Missions
Chapter 6 Flight Application  “Wide Angle Camera” Operations 1. Adjust the Wide Angle Zoom Factor While shooting, tap the " " dynamic icon, and the wide angle zoom factor setting window will pop up. A maximum of 16x digital zoom is supported. You can drag up or down to zoom in or out on the picture captured by the wide angle camera, so as to flexibly shoot objects at different distances.
Page 143 Chapter 6 Flight Application Fig 6-9 Waypoint (before taking off) Table 6-8 “Waypoint Mission” Terms and Details Term Definition Refers to the vertical height of the aircraft relative to the take-off point. Altitude Refers to the vertical height of the aircraft relative to sea level. It is used to set the position where the nose of the aircraft is facing.
Page 144 Chapter 6 Flight Application Table 6-9 "Waypoint Mission" Icons and Details Icon Meaning Description Tap this icon to add a waypoint on the map as needed. Waypoint Settings Every two neighboring waypoints connect to form a flight segment and one or more flight segments form a route.
Page 145 Chapter 6 Flight Application  Add Waypoints Tap the “ ” icon, find the starting point for the mission on the map and tap it to create the first waypoint, and then repeat the previous operation to create multiple waypoints as required.
Page 146 Chapter 6 Flight Application  The maximum value for the flight altitude setting will be dynamically adjusted according to the altitude limit set in the "Flight Control Parameter Setting".  After take-off, the aircraft will gradually adjust its "flight altitude" and "flight speed" to the set values while flying to this waypoint.
Page 147 Chapter 6 Flight Application 11. Add a Waypoint Action On the waypoint settings interface, tap the "Add Action +" button under “Waypoint Action” to set “Camera Action” and “Aircraft Action” for the current waypoint. You can add a maximum of 10 waypoint actions for one waypoint.
Page 148: Polygon Mission
Chapter 6 Flight Application 2. Set Link Waypoint Tap the waypoints to be associated under "Link Waypoint(s)" to associate the current point of interest with the selected waypoints.  After a waypoint is associated with a point of interest, the yaw angle of the aircraft at the waypoint will not be set to “Align Route”...
Page 149 Chapter 6 Flight Application Fig 6-10 Polygon (Before taking off) Table 6-10 "Polygon Mission" Terms and Details Term Definition Refers to the vertical altitude of the work surface of the shot object Relative Height relative to the take-off point of the aircraft. Ground Sampling Distance.
Page 150 Chapter 6 Flight Application When enabled, the aircraft will switch from one main route to an Coordinated Turns adjacent main route along the optimal arc-shaped path. Table 6-11 “Polygon Mission” Icons and Details Icon Meaning Description Delete Tap this icon to delete polygon point selected. Tap this button, and then tap the "Confirm"...
Page 151 Chapter 6 Flight Application  A polygonal area includes two waypoints, that is, the starting point ( ) and the end point  Mission Setting 1. Choose Gimbal and Camera Lens Tap “Gimbal Model” drop-down list to set the model of the gimbal that executes the polygon mission;...
Page 152 Chapter 6 Flight Application  The setting range of the front overlap and side overlap is 10%-90%, and the default value is 70%. 8. Turn On/Off Elevation Optimization  If this function is turned on, the aircraft will create a route along the center point of the polygon for re-shooting after completing the shooting of the main route.
Page 153: Pre-Flight Check
Chapter 6 Flight Application Important  In A-Mesh Link mode, when an aircraft (not the relay one) in the team is selected, the relay aircraft should take off in advance to ensure stable communication link path in air.  In A-Mesh Link mode, when all aircrafts in the team are selected (“ALL” selected”) executes waypoint mission, each aircraft will execute one part of the polygon mission.
Page 154: Resume Mission
Chapter 6 Flight Application 6.9.4 Resume Mission When an abnormal situation such as an abnormal exit occurs during a flight mission, tap the " " icon to enter the "Mission" interface. This will trigger the “Resume Mission” function, and a prompt window will pop up.
Page 155: Mission Library
Chapter 6 Flight Application  Modeling Surround After modeling surround is enabled, the aircraft will automatically circle around the current position, flying clockwise at a certain distance, and shooting at the target directly below the center point, so as to collect images of the mission location from all directions. Important ...
Page 156: Personal Center
Tap the “ ” icon (in the toolbar or Shortcuts) to enter the "Personal Center" interface. When using the product for the first time, you need to register and log in to Autel Robotics cloud service account. On the “Personal Center” interface, you can perform the following operations: 1.
Page 157: Chapter 7 Firmware Updates And Maintenance
7.2 Aircraft Parts Maintenance To ensure the optimal performance of the aircraft, regular maintenance is required for the aircraft parts. For more information, see “Maintenance Manual”. If you have any questions, please contact Autel Robotics After-Sales Support.
Page 158 Autel Robotics UPC: 889520212342  You can independently contact Autel Robotics to purchase the aforementioned parts and follow the operation instructions for replacement.  If the part that you want to replace is not listed in the above lists, please contact Autel...
Page 159: Troubleshooting Guide
 The following troubleshooting measures are only limited to failures resulting from normal usage.  For failures resulting from abnormal usage, please contact Autel Robotics for handling. 1. The remote controller cannot power on:  Check whether the remote controller has sufficient power. If the battery level is too low, it may result in a power-on failure after shutdown.
Page 160  If the gimbal successfully passes the self-check, but the aircraft still reports a fault, it may be a hardware failure of the aircraft. In this case, contact Autel Robotics. 4. There is no response from the remote controller when matching it with the aircraft: ...
Page 161 Chapter 7 Firmware Updates and Maintenance 10. The gimbal camera automatically turns off during recording:  Do not immediately remove the microSD card from the aircraft. Instead, restart the camera and wait for the video file to be stored as much as possible. ...
Page 162  Restart the device. If it can power on normally, make sure that the device is sufficiently charged before proceeding with the update.  If the device cannot power on, contact Autel Robotics. 18. Restore the factory setting of the remote controller: ...
Page 163: Appendix A Product Specifications
Appendix A Product Specifications Appendix A Product Specifications A.1 Aircraft Aircraft 1640 g (ABX40 smart battery, Fusion 4T Gimbal, and EVO Max 4T Weight propellers included) EVO Max 4T Maximum 1890 g Take-Off Mass (MTOM) 1665 g (ABX40 smart battery, Fusion 4N Gimbal, and EVO Max 4N Weight propellers included) EVO Max 4N Maximum...
Page 164 Appendix A Product Specifications Maximum Service Ceiling 4000 meters (use ABX40 smart battery); Above Sea Level 3000 meters (use ABX41 smart battery). Maximum Flight Altitude 800 meters (Altitude limit in the Flight Application) Maximum Flight Time 42 minutes (Windless) Maximum Range 25 km Maximum Hovering Time 38 minutes...
Page 165 Appendix A Product Specifications 5.2G：5.15-5.25GHz**，5.17-5.25GHz*** 5.8G：5.725-5.829GHz*，5.725-5.850GHz *Only applies to SRRC regions ** Only applies to FCC, CE (Germany excluded) and UKCA regions *** Only applies to Germany Note: Some frequencies are only applicable in some regions or only used in door. For details, please refer to local laws and regulations.
Page 166 Appendix A Product Specifications Forward: 0.5 - 31 m Backward: 0.5 - 25 m Sensing Range Sidewards: 0.5 - 26 m Upward: 0.2 - 26 m Downward: 0.3 - 23 m Forward & Backward: 60°(H), 80°(V) Upward: 180° (sidewards), 120° (forward & backward) Downward: 180°...
Page 167 Appendix A Product Specifications Supports downward sensing, and its sensing range varies by the ground material. For example, the sensing range of cement ground is 12 meters, and the sensing range of grass with a thickness of more than 3 cm is less than 6 meters. To comply with (national) regional regulations, certain aircraft versions use a 24 GHz millimeter-wave radar in the downward direction and use 60 GHz radars in the forward, backward,...
Page 168: Gimbal
Appendix A Product Specifications A.2 Gimbal A.2.1 Fusion 4T (EVO Max 4T) Zoom Camera Image Sensor 1/2" CMOS. Effective pixels: 48M Focal length: 11.8 - 43.3 mm 35 mm equivalent focal length: 64 - 234 mm Lens Aperture: F2.8 - F4.8 Focusing distance: 5 m ~ ∞...
Page 169 Appendix A Product Specifications Video Resolution 4000×3000 30P Video Format Video Encoding H.264/H.265 Supported File Systems exFAT/FAT32 Infrared Thermal Imaging Camera Image Sensor Uncooled VOx Microbolometer FOV: 42° Focal length: 13 mm Lens Aperture: F1.2 Focusing distance: 6 m ~ ∞ Sensitivity ≤50mK@F1.0, 25°C Pixel Pitch...
Page 170: Fusion 4N (Evo Max 4N)
Appendix A Product Specifications Laser Rangefinder Wavelength 905 nm ± (1 m + D×0.15%) Measurement Accuracy where D is the distance to a vertical reflecting plane Measuring Range 5 - 1200 m Gimbal Pitch: -135° to 45° Mechanical Range Roll: -45° to 45° Yaw: -45°...
Page 171 Appendix A Product Specifications Video Encoding H.264/H.265 Supported File Systems exFAT/FAT32 Wide Angle Camera Image Sensor 1/1.28" CMOS. Effective pixels: 50M DFOV: 85° Focal length: 4.5 mm Equivalent focal length: 23 mm Lens Aperture: F1.9 AF motor: 8-line SMA, PDAF focusing Focusing distance: 1 m ~ ∞...
Page 172 Appendix A Product Specifications Range Radiometric Measurement ±2°C or reading ±2% (using the larger value) @ ambient Accuracy temperature ranges from -20°C to 60°C Accurate Temperature 1 ~ 25 m Measurement Distance Digital Zoom 16x digital zoom and link zoom is supported In area temperature measurement, high and low temperature Temperature Alert alarm thresholds, reporting coordinates and temperature...
Page 173: Remote Controller
Appendix A Product Specifications A.3 Remote Controller Autel Smart Controller V3 Material PC+ABS 269×189×66 mm (antennas folded) Dimensions 269×302×87 mm (antennas unfolded) 1194 g (protective case excluded) Weight 1365 g (protective case included) Operating Temperature -20°C to 40°C +15°C ~ +25°C (within a year) Storage Temperature 0°C ~ +30°C (within three months) -20°C ~ +45°C (within a month)
Page 174 Appendix A Product Specifications 2.4G: ≤30dBm（FCC/ISED）; ≤20dBm（CE/SRRC/UKCA） Wi-Fi Effective Isotropic Radiated Power (EIRP) 5.8G: ≤30dBm（FCC/ISED/SRRC）; ≤14dBm（CE/UKCA） Bluetooth Bluetooth 5.0 Bluetooth Operating 2.400 - 2.4835 GHz Frequency Bluetooth Effective Isotropic Radiated Power ≤20dBm (EIRP) Image Transmission Antenna Dual antennas, 1T2R, detachable design 900M: 902-928MHz* 2.4G: 2.400–2.476GHz**, 2.400–2.4835GHz 5.8G: 5.725-5.829GHz**, 5.725-5.850GHz...
Page 175: Smart Battery
Appendix A Product Specifications Touch Control Supports 10-point touch Battery Battery Type Li-Po 3S Rated Capacity 5800 mAh Voltage 11.55V Battery Energy 67 Wh Charging Time About 120 minutes 2.5 hours (Max brightness) Battery Endurance 4.0 hours (50% brightness) Battery Replacement Not supported A.4 Smart Battery ABX40 Smart Battery...
Page 176 Appendix A Product Specifications ABX41 Smart Battery Battery Dimension 158.4×74.3×50.7 mm Operating Temperature -20°C to 50°C Battery Type LiPo 4S Rated Capacity 9248mAh Battery Energy 136.5Wh Voltage 14.76V Charging Voltage Limit 17.0V Rated Charging Power 120W Maximum Charging Power 247W Weight 533 g +5°C ~ +45°C*...
Page 177: Appendix B Declaration Of Conformity
Manufacturer’s Address: 601,701,801,901, Block B1, Nanshan iPark, No. 1001 Xueyuan Avenue, Nanshan District, Shenzhen, Guangdong, China We, Autel Robotics Co., Ltd., declare under our sole responsibility that the above referenced product is in conformity with the applicable requirements of the following directives:...
Page 178 The notified body, LGAI Technological Center S.A./Applus, notified body number: 0370, performed the EU-type examination in according with Annex Part 8, Module B of Regulation (EU) 2019/945, and issued the EU-type examination certificate: 0370-UAS-0008. Signed for and on behalf of: Autel Robotics Co., Ltd. Place: Shenzhen, China Date: 2024-01-12...

This manual is also suitable for:

Evo max 4t Evo max 4n

Autel Robotics EVO Max Series User Manual

Chapter 1 Product Overview

Chapter 2 Flight Safety

Chapter 3 Aircraft

Chapter 4 Remote Controller

Chapter 5 Smart Battery

Chapter 6 Flight Application

Chapter 7 Firmware Updates and Maintenance

Appendix A Product Specifications

Appendix B Declaration of Conformity

Quick Links

Need help?

Questions and answers

Related Manuals for Autel Robotics EVO Max Series

Summary of Contents for Autel Robotics EVO Max Series

This manual is also suitable for:

Table of Contents
