by image number.=
-firmwareupdate=[firmware update mode]
Set the firmware update mode to "auto", "dontupdate", "forceupdate". The default mode is "auto."
-help
Display a list of available commands.
8.3.3 Examples
The commands should be separated by a space. Every command start with a "-" character,
arguments follow the "=" character.
8.3.3.1 Typical Usage
CycloneControlConsole.exe –cyclone=10.0.1.1 –launchimage=1
This example connects to a single Cyclone identified by its IP address 10.0.1.1 and executes its
first image. This is the most common usage of the Cyclone Control Utility.
CycloneControlConsole.exe –cyclone=USB1 –launchimage=1
This example connects to a single Cyclone enumerated on USB1 and executes its first image.
8.3.3.2 Controlling Multiple Cyclones
CycloneControlConsole.exe –cyclone=USB1,10.0.1.2,10.0.1.3 –
launchimage=2
This example connects to three separate Cyclone units. Two units are connected via USB
(10.0.1.1 and 10.0.1.2) and the third is connected via Ethernet (10.0.1.3). The three Cyclone units
are configured to execute image #2.
8.3.3.3 Programming Dynamic Data
CycloneControlConsole.exe –cyclone=CycloneFX_Table1,CycloneFX_Table2
–launchimage=1 –putdynamicdata=2,1080,45,44,49,53,4F,4E
Here, a Cyclone is connected via the Serial port and is identified by name rather than IP address.
After executing image #1 on both cyclones, we write 6 bytes of dynamic data on Cyclone #2
starting at address 0x1080. Note that all parameters for the "-putdynamicdata" command should
be hexadecimal values.
