Figure 3-7: Mini 10-Pin and Mini 20-Pin Keyed Header Dimensions
3.18

Target Headers For Part# CYCLONE_ACP_FX

PEmicro Part# CYCLONE_ACP_FX features 3 ports labeled A-C.
3.18.1 PORT A: 10-Pin Keyed Mini Connector (Kinetis, S32 (ARM), other PEmicro-Supported ARM
devices)
3.18.1.1 JTAG Pin Assignments
The Cyclone provides a keyed 10-pin 0.050-inch pitch double row connector for ARM targets. The
location of the this header is indicated as PORT A in Figure 3-5. The 10-pin keyed mini connector
pin definitions for JTAG mode are as follows:
10-Pin Keyed Mini Connector JTAG Mode Pin Assignments
Note: *The pin is reserved for internal use within the PEmicro interface.
CYCLONE
clock and single bi-directional data pin.
3.18.1.2 SWD Mode Pin Assignments
10-Pin Keyed Mini Connector SWD Mode Pin Assignments
Note: *The pin is reserved for internal use within the PEmicro interface.
SWD Mode is selected from the "Communication Mode" drop-down box in the Cyclone Image
Creation Utility:
User Manual For CYCLONE
PIN 1 - TVCC
PIN 3 - GND
PIN 5 - GND
PIN 7 - NC
PIN 9 - NC*
FX programmers also support SWD Mode. This replaces the JTAG connection with a
PIN 1 - TVCC TMS/SWDIO - PIN 2
PIN 3 - GND TCK/SWCLK - PIN 4
PIN 5 - GND
PIN 7 - NC
PIN 9 - NC*
Figure 3-8: Communications Mode Selection
FX Programmers
TMS - PIN 2
TCK - PIN 4
TDO - PIN 6
TDI - PIN 8
RESET - PIN 10
NC* - PIN 6
NC* - PIN 8
RESET - PIN 10
10
