3-5.
*The pin is reserved for internal use within the PEmicro interface.
3.19.8 PORT H: 20-Pin Debug Connector (Kinetis, S32 (ARM), other PEmicro-Supported ARM
devices)
3.19.8.1 JTAG Mode Pin Assignments
The Cyclone provides a 20-pin 0.100-inch pitch double row connector for ARM targets. The
location of the this header is indicated as PORT H under Part# CYCLONE_UNIVERSAL_FX in
Figure 3-5. The 20-pin standard connector pin definitions for JTAG mode are as follows:
20-Pin Standard Connector JTAG Mode Pin Assignments
*The pin is reserved for internal use within the PEmicro interface.
3.19.8.2 SWD Mode Pin Assignments
CYCLONE
clock and single bi-directional data pin.
20-Pin Standard Connector SWD Mode Pin Assignments
*The pin is reserved for internal use within the PEmicro interface.
SWD Mode is selected from the "Communication Mode" drop-down box in the Cyclone Image
Creation Utility:
User Manual For CYCLONE
Power MPC5xx/8xx BDM Pinout
NC* 1 2
GND 3 4
GND 5 6
HRESET# 7 8
VDD 9 10
PIN 1 - TVCC
PIN 3 - TRST or NC*
PIN 5 - TDI
PIN 7 - TMS
PIN 9 - TCK
PIN 11 - NC*
PIN 13 - TDO
PIN 15 - RESET
PIN 17 - NC*
PIN 19 - NC*
FX programmers also support SWD Mode. This replaces the JTAG connection with a
PIN 1 - TVCC
PIN 3 - TRST or NC*
PIN 5 - NC*
PIN 7 - TMS/SWDIO
PIN 9 - TCK/SWCLK
PIN 11 - NC*
PIN 13 - NC*
PIN 15 - RESET
PIN 17 - NC*
PIN 19 - NC*
FX Programmers
SRESET#
DSCLK
NC*
DSDI
DSDO
NC - PIN 2*
GND - PIN 4
GND - PIN 6
GND - PIN 8
GND - PIN 10
GND - PIN 12
GND - PIN 14
GND - PIN 16
GND - PIN 18
GND - PIN 20
NC* - PIN 2
GND - PIN 4
GND - PIN 6
GND - PIN 8
GND - PIN 10
GND - PIN 12
GND - PIN 14
GND - PIN 16
GND - PIN 18
GND - PIN 20
