P&E CYCLONE FX User Manual page 121

11.6.5.3 Loading a Barcode Test (.bar) File
PEmicro JSON Barcode Test (.bar) Information can be loaded into this utility so it can be edited
further or to test other barcodes.
To load a Barcode Test (.bar) file, click on the Load File button in the control area of the main
screen.
If a filename (editable) exists in the control area, the program tries to load test information from that
file. If no filename exists, then the window shown below is opened to search for and/or edit a
filename. If Open is clicked, the program attempts to load the test information from that file. On
attesting to load a file, the button is recolored respectively on Success or Failure to Load File
LoadFile
11.6.6 Advanced Program Use
11.6.6.1 Bulk Copy Option
Often, it is required to make many transfers from Sample characters to Char Test(TYPE):
entries or from Char Test(TYPE): entries to Range-1 or Range-2. These transfers are usually
done by individually clicking on appropriate down arrows. For large barcodes, this can be very time
consuming. With Bulk Copy, Sample characters can be selected / deselected by a mouse entry
User Manual For CYCLONE
Figure 11-25: Save PEmicro JSON File Window
Figure 11-26: Program Control Area
.
Figure 11-27: Load PEmicro JSON File Window
FX Programmers
or
116
