4 User Interface Symbols – Parameter and Softkey Symbols
Sym- Setup Parameters and their significance
bols Page
Complete overviews of all symbols are included in the full operating instructions.
All measurements: Ref.voltage L-PE: voltage to which the measured values for leakage current
1/3
have been standardized; Gnd fault sens.: continuous residual current monitoring (10/30 mA)
Automatic measurements: set parameters for test sequences: start and end view,
inclusive operation uncertainty (yes/no), auto measurement point (yes/no)
Database:
1/3
with inserted USB stick
System: set general device parameters;
1/3
date/time,
Printer: printer selection for USB master interface
2/3
Tester:
2/3
Culture: select language for operating instructions, keyboard and measuring
2/3
sequences by acknowledging the respective national flag; Reboot necessary!
Optionally connected external devices
2/3
USB stick,
System information: query software and hardware version, serial number, build
3/3
number, calibration data and storage occupancy
— Functions and their significance
Set classification parameters for the respective test sequence
(test sequences: switch settings AUTO, A1 ... A8)
Accept parameters, acknowledge message
Abort single measurement or test sequence
Evaluate measurement of visual inspection with OK or not OK (toggle key)
Continue test, next test step in the test sequence
Symbol left: Direct selection key measurement type (connection type...) or measur-
ing method (direct ...) / Symbol right: Selection between two states (no submenu)
Start evaluation – record measured value. Each time this softkey is pressed, an
additional measured value is saved and the number is increased by one.
Symbol left: Repeat measured value recording
Symbol right: Repeat test step in the test sequence
Symbol left: Delete measured value
Symbol right: Skip individual tests in the test sequence
Display measured values from performed measurements and test sequences
Magnifying glass symbol: show (+) or hide (–) details regarding database objects
or selected measurements
Enter a new ID for a test object either before or after a test, and in case the ID
has not yet been entered to the structure
Save measurement data / save measurement data as (with display of directory
path / ID or new entry of an ID other than the preselected one)
8
& SECULIFE ST
RO
deletion,
:
volume,
connected,
select tester from list,
keyboard / barcode scanner,
(25)
BASE
statistics,
save, restore database
brightness,
disconnected
add new tester
default settings,
printer
GMC-I Messtechnik GmbH
Symbols
self-test
