8.10 U – Measuring Voltage
SECUTEST PRO and SECULIFE ST BASE only:
1 Select measuring function
U
2
Select parameters
3 Set parameters
Meas. Parameter
Mode (Measurement type)
V – COM
V – COM (with mains) Effective value + AC + DC;
4
Connect DUT
Measuring Voltage
COM V
Attention!
!
Only use the enclosed contact-pro-
tected KS17-ONE measurement
cables for the measurement of dangerous
voltages, please.
GMC-I Messtechnik GmbH
& SECULIFE ST
RO
Meaning
Effective value + AC + DC
for permanently connected DUTs
for line voltage at test socket
V – COM (with mains)
(25)
BASE
Special case: permanently installed DUT
COM
➭ For testing mains power packs and charging
units: Connect the DUT mains terminal
with the test socket.
➭ Connect the DUT output, e.g. for mea-
suring safety extra low voltage (SELV),
with sockets V and COM.
5
Start test
6
Acknowledge line voltage warning
Only for measurement
type: (with mains)
7
Save measured values to clipboard
8 Stop test
9
Save measurements under ID no.
Single Measurements
Meas. Volt.
V
!
V – COM
21
