Layout and Function
On and Off Keys
(6 and 7)
Page 12
3.2
The compressor can be turned on and off directly via the On and Off keys:
Key Designation
On key
Off key
Tab. 3.3: Functions of the On and Off keys
The On and Off key functions are only used to operate the compressor.
To switch off the control completely, the compressor must be disconnected
from the grid. This is because the compressor supplies power to the control.
Layout of the Control Unit
Function
– To switch on the compressor.
(If the network pressure is greater than the lower switch-on
pressure of the compressor, the compressor remains in
standby when the On key is pressed.)
– To switch off the compressor.
– To acknowledge a network failure (unless the Auto-
Restart function is activated).
BOGE base control for scroll compressors
